Features:
- Audible alarm(s): Yes
- Noise level: 55 dB
- Output power: 2700 W
- Output operation voltage (min): 220 V
- Surge energy rating: 340 J
- Output operation voltage (max): 240 V
- Web-based management: Yes
- Input operation voltage (min): 100 V
- Input frequency: 40/70 Hz
- Output power capacity: 3 kVA
- Efficiency: 93.5%
- UPS topology: Double-conversion (Online)
- Emergency Power Off (EPO): Yes
- Input operation voltage (max): 275 V
- Waveform: Sine
- Surge protection: Yes
- Crest factor: 3:1
- Output frequency regulation: 50/60 Hz
- Output frequency: 50/60 Hz
- Auto-restart: Yes
Design:
- LED indicators: Yes
- Form factor: Tower
- Cable length: 2.44 m
- International Protection (IP) code: IP20
- Product colour: Black
- Display type: LCD
Operational conditions:
- Operating altitude: 0 - 3000 m
- Operating temperature (T-T): 0 - 40 °C
- Storage relative humidity (H-H): 0 - 95%
- Storage temperature (T-T): -15 - 45 °C
- Operating relative humidity (H-H): 0 - 95%
- Non-operating altitude: 0 - 15000 m
Weight & dimensions:
- Height: 432 mm
- Depth: 635 mm
- Width: 85 mm
- Weight: 31.3 kg
Packaging data:
- Package width: 599 mm
- Package weight: 36.7 kg
- Package depth: 871 mm
- Package height: 246 mm
- Warranty card: Yes
- Bracket: Yes
- Software CD: Yes
Packaging content:
- Cables included: USB cable
- Quick installation guide: Yes
- Rack mount kit: Yes
Ports & interfaces:
- Power plug: C20 coupler
- USB port: Yes
- AC outlets quantity: 10 AC outlet(s)
- AC outlet types: C19 coupler, C13 coupler
- Number of output IEC jumpers: 2
- Serial interface type: RJ-45
- Serial interface: Yes
- SmartSlot: Yes
Battery:
- Battery technology: Sealed Lead Acid (VRLA)
- Typical backup time at half load: 11.8 min
- Battery recharge time: 3 h
- Automatic battery test: Yes
- Number of batteries supported: 1
- Cold start: Yes
- Hot-swap battery: Yes
- Typical backup time at full load: 4 min
- Battery capacity: 505 VAh
- Battery life (max): 5 year(s)
Logistics data:
- Total carbon footprint (kg of CO2e): 5053.66
- Harmonized System (HS) code: 85078000
