Leírás és Paraméterek
Processor:
- Maximum number of SMP processors: 1
- Compatible processor series: AMD Ryzen™ 5, AMD Ryzen™ 3
- Processor socket: Socket AM5
- Processor manufacturer: AMD
Features:
- Motherboard chipset family: AMD
- Component for: Server
- Motherboard chipset: AMD B650 Express
- PC health monitoring: Voltage, Fan, CPU
- Motherboard form factor: micro ATX
Memory:
- ECC сompatibility: ECC & Non-ECC
- Supported memory types: DDR5-SDRAM
- Memory slots type: DIMM
- Memory voltage: 1.1 V
- Maximum internal memory: 32 GB
- Supported memory clock speed (max): 5200 MHz
- Number of memory slots: 4
- Supported memory clock speeds: 3600, 5200
Operational conditions:
- Storage temperature (T-T): -40 - 70 °C
- Operating relative humidity (H-H): 20 - 90%
- Operating temperature (T-T): 10 - 35 °C
Weight & dimensions:
- Depth: 243.8 mm
- Width: 243.8 mm
Network:
- Wi-Fi: No
- Ethernet LAN: Yes
Internal I/O:
- TPM connector: Yes
- ATX Power connector (24-pin): Yes
- EPS power connector (8-pin): Yes
- Number of COM connectors: 1
- Number of SATA III connectors: 4
BIOS:
- BIOS type: UEFI AMI
- ACPI version: 6.4
- System Management BIOS (SMBIOS) version: 3.5
- BIOS memory size: 256 Mbit
Storage controllers:
- RAID support: Yes
- RAID levels: 0, 1, 10
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- Serial ports quantity: 1
- Ethernet LAN (RJ-45) ports: 2
- IPMI LAN (RJ-45) port: Yes
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- VGA (D-Sub) ports quantity: 1
