Leírás és Paraméterek
Processor:
- Compatible processor series: AMD Ryzen™ 7000 Series
- Maximum number of SMP processors: 1
- Processor manufacturer: AMD
- Processor socket: Socket AM5
Features:
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Motherboard chipset: AMD B650
- Motherboard form factor: Mini-ITX
- Motherboard chipset family: AMD
- Audio chip: Realtek ALC897
- Audio output channels: 7.1 channels
Memory:
- Memory slots type: DIMM
- Maximum internal memory: 96 GB
- Supported memory types: DDR5-SDRAM
- Memory channels: Dual-channel
- Number of memory slots: 2
- Unbuffered memory: Yes
Weight & dimensions:
- Depth: 170 mm
- Width: 170 mm
Network:
- Wi-Fi standards: 802.11a, Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 6E (802.11ax)
- Bluetooth version: 5.2
- LAN controller: Dragon RTL8125BG
- Ethernet LAN: Yes
- Bluetooth: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Ethernet interface type: 2.5 Gigabit Ethernet
- Wi-Fi: Yes
Internal I/O:
- USB Type-C socket on the front panel: Y
- RGB LED pin header: Yes
- Front panel audio connector: Yes
- Number of SATA III connectors: 2
- EPS power connector (8-pin): Yes
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- USB 2.0 connectors: 1
Storage controllers:
- RAID levels: 1, 10, 0
- Number of storage drives supported: 4
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
- Supported storage drive types: HDD & SSD
Rear panel I/O ports:
- Wi-Fi antenna socket: Yes
- Microphone in: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
- BIOS switch button: Yes
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 4
- HDMI ports quantity: 1
- Line-in: Yes
Expansion slots:
- Number of M.2 (M) slots: 1
- PCI Express x1 (Gen 4.x) slots: 1
