Leírás és Paraméterek
Processor:
- Processor socket: Socket AM5
- Compatible processor series: AMD Ryzen™ 7
- Processor manufacturer: AMD
Features:
- Motherboard form factor: micro ATX
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Motherboard chipset: AMD B650
- Motherboard chipset family: AMD
- Audio output channels: 7.1 channels
- Audio chip: Realtek ALC897
Memory:
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- Number of memory slots: 2
- Maximum internal memory: 64 GB
- Unbuffered memory: Yes
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Depth: 226 mm
- Width: 244 mm
Network:
- Ethernet LAN: Yes
- Wi-Fi: No
- Ethernet interface type: 2.5 Gigabit Ethernet
- LAN controller: Realtek RTL8125-BG
Internal I/O:
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- Thunderbolt headers: 1
- EPS power connector (8-pin): Yes
- USB 2.0 connectors: 2
- Front panel audio connector: Yes
- Number of SATA III connectors: 4
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- ATX Power connector (24-pin): Yes
- TPM connector: Yes
- CPU fan connector: Yes
Storage controllers:
- RAID levels: 1, 10, 0
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- RAID support: Yes
Rear panel I/O ports:
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- Line-in: Yes
- USB 2.0 ports quantity: 4
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- DisplayPorts quantity: 1
- Microphone in: Yes
- DisplayPort version: 1.4
- HDMI ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x1 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 1
