Leírás és Paraméterek
Processor:
- Processor manufacturer: AMD
- Supported processor sockets: Socket AM5
- Compatible processor series: AMD Ryzen 7000 Series
- Processor socket: Socket AM5
Graphics:
- Parallel processing technology support: Crossfire
- Maximum resolution: 3840 x 2160 pixels
- HDCP: Yes
Features:
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Motherboard chipset: AMD B650
- Product colour: Black
- Audio chip: Realtek ALC897
- Motherboard chipset family: AMD
- Audio output channels: 7.1 channels
- Motherboard form factor: micro ATX
Memory:
- Memory slots type: DIMM
- Supported memory clock speed (max): 7200 MHz
- Unbuffered memory: Yes
- Supported memory clock speeds: 6800, 6600, 5200, 7000, 6200, 5600, 7200, 6400, 6000, 4400 MHz, 4800
- Number of memory slots: 4
- Supported memory types: DDR5-SDRAM
- Maximum internal memory: 192 GB
- ECC сompatibility: ECC & Non-ECC
Weight & dimensions:
- Width: 244 mm
- Depth: 244 mm
Network:
- LAN controller: Dragon RTL8125BG
- Ethernet interface type: 2.5 Gigabit Ethernet
- Wi-Fi: No
- Ethernet LAN: Yes
Internal I/O:
- Number of SATA III connectors: 4
- Thunderbolt headers: 1
- CPU fan connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
- EPS power connector (8-pin): Yes
- TPM connector: Yes
- Front panel audio connector: Yes
- 12V power connector: Yes
- USB 2.0 connectors: 2
- RGB LED pin header: Yes
- Number of chassis fan connectors: 3
- Chassis intrusion connector: Yes
- ATX Power connector (24-pin): Yes
Packaging content:
- Cables included: SATA
- Screws included: Yes
Storage controllers:
- RAID support: Yes
- Supported storage drive types: HDD & SSD
- RAID levels: 0, 10, 1
- Number of storage drives supported: 7
- Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 5.0, SATA III
Rear panel I/O ports:
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- DisplayPorts quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- DisplayPort version: 1.4
- USB connector type: USB Type-A, USB Type-C
- Microphone in: Yes
- Headphone outputs: 3
- USB 2.0 ports quantity: 4
- HDMI ports quantity: 1
- HDMI version: 2.1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x16 (Gen 3.x) slots: 1
- Number of M.2 (M) slots: 3
