Leírás és Paraméterek
Processor:
- Supported processor sockets: LGA 1700
- Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3
- Processor manufacturer: Intel
- Processor socket: LGA 1700
Features:
- Audio output channels: 7.1 channels
- Motherboard chipset family: Intel
- Product colour: Black
- Audio chip: Realtek ALC897
- Motherboard chipset: Intel B760
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Motherboard form factor: Mini-ITX
Memory:
- Maximum internal memory: 96 GB
- Supported memory types: DDR5-SDRAM
- Memory channels: Dual-channel
- Number of memory slots: 2
- Unbuffered memory: Yes
- Memory slots type: DIMM
- Supported memory clock speed (max): 8600 MHz
Weight & dimensions:
- Width: 170 mm
- Depth: 170 mm
Network:
- Ethernet interface type: 2.5 Gigabit Ethernet
- Bluetooth version: 5.3
- Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11b, 802.11 axe, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), 802.11g
- Top Wi-Fi standard: Wi-Fi 6E (802.11axe)
- Wi-Fi: Yes
- Ethernet LAN: Yes
- LAN controller: Dragon RTL8125BG
- Bluetooth: Yes
Internal I/O:
- ATX Power connector (24-pin): Yes
- 12V power connector: Yes
- EPS power connector (8-pin): Yes
- Front panel audio connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- CPU fan connector: Yes
- USB 2.0 connectors: 1
- Number of SATA III connectors: 3
- Number of chassis fan connectors: 2
- USB Type-C socket on the front panel: Y
- Number of addressable LED slots: 2
Packaging content:
- Cables included: SATA
- Antenna included: Yes
- Screws included: Yes
Storage controllers:
- RAID levels: 0, 1, 5
- Number of storage drives supported: 5
- RAID support: Yes
- Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
- Supported storage drive types: HDD & SSD
Rear panel I/O ports:
- HDMI ports quantity: 1
- Number of USB 3.2 Gen 1 ports: 4
- Ethernet LAN (RJ-45) ports: 1
- USB connector type: USB Type-C, USB Type-A
- Line-out: Yes
- MIC input: 1
- DisplayPort version: 1.4
- WiFi-AP antenna jack: 2
- Number of USB 3.2 Gen 2 Type-C ports : 1
- DisplayPorts quantity: 1
- Number of USB 3.2 Gen 2 Type-A ports: 1
- SPDIF optical output: Y
Expansion slots:
- Number of M.2 (M) slots: 2
- PCI Express x16 (Gen 5.x) slots: 1
