Leírás és Paraméterek
Processor:
- Processor socket: LGA 1700
- Compatible processor series: Intel Core i3 12th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i5 12th Gen, Intel Core i9 14th Gen, Intel Core i7 12th Gen, Intel Core i9 13th Gen, Intel Core i7 13th Gen, Intel Core i3 13th Gen
- Processor manufacturer: Intel
Features:
- Motherboard chipset family: Intel
- Audio chip: Realtek ALC897
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Audio output channels: 7.1 channels
- Motherboard form factor: micro ATX
- Motherboard chipset: Intel B760
Memory:
- ECC сompatibility: Non-ECC
- Maximum internal memory: 96 GB
- Number of memory slots: 2
- Supported memory types: DDR5-SDRAM
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Unbuffered memory: Yes
Weight & dimensions:
- Width: 244 mm
- Depth: 201 mm
Network:
- Wi-Fi: No
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- LAN controller: Dragon RTL8125BG
Internal I/O:
- CPU fan connector: Yes
- TPM connector: Yes
- Front panel audio connector: Yes
- USB 2.0 connectors: 2
- RGB LED pin header: Yes
- Number of SATA III connectors: 4
- ATX Power connector (24-pin): Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Packaging content:
- Cables included: SATA
- Screws included: Yes
Storage controllers:
- RAID levels: 1, 10, 5, 0
- RAID support: Yes
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- DisplayPort version: 1.4
- VGA (D-Sub) ports quantity: 1
- Microphone in: Yes
- Line-in: Yes
- DisplayPorts quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 2
Expansion slots:
- Number of M.2 (M) slots: 1
- PCI Express x1 (Gen 3.x) slots: 2
- PCI Express x16 (Gen 4.x) slots: 1
