Leírás és Paraméterek
Processor:
- Processor socket: LGA 1700
- Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5
- Maximum number of SMP processors: 1
- Processor manufacturer: Intel
Features:
- Audio output channels: 7.1 channels
- Motherboard form factor: micro ATX
- Audio chip: Realtek ALC897
- Motherboard chipset family: Intel
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Motherboard chipset: Intel B760
Memory:
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- ECC сompatibility: Non-ECC
- Memory channels: Dual-channel
- Number of memory slots: 4
- Maximum internal memory: 256 GB
Weight & dimensions:
- Width: 244 mm
- Depth: 244 mm
Network:
- Wi-Fi: No
- Ethernet interface type: 2.5 Gigabit Ethernet
- Ethernet LAN: Yes
- LAN controller: Realtek RTL8125-BG
Internal I/O:
- ATX Power connector (24-pin): Yes
- Number of SATA III connectors: 4
- USB 2.0 connectors: 6
- TPM connector: Yes
- CPU fan connector: Yes
- Front panel audio connector: Yes
- Thunderbolt headers: 1
- RGB LED pin header: Yes
Storage controllers:
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- DisplayPorts quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- DisplayPort version: 1.4
- HDMI ports quantity: 1
- Microphone in: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- Line-in: Yes
- PS/2 ports quantity: 1
- USB 2.0 ports quantity: 2
Expansion slots:
- Number of M.2 (M) slots: 1
- PCI Express x16 (Gen 3.x) slots: 1
- PCI Express x16 (Gen 5.x) slots: 1
