Leírás és Paraméterek
Processor:
- Maximum number of SMP processors: 1
- Processor socket: LGA 1700
- Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5
- Processor manufacturer: Intel
Features:
- Motherboard form factor: micro ATX
- Audio chip: Realtek ALC897
- Motherboard chipset family: Intel
- Motherboard chipset: Intel B760
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
Memory:
- Unbuffered memory: Yes
- Maximum internal memory: 128 GB
- ECC сompatibility: Non-ECC
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Number of memory slots: 4
- Supported memory types: DDR5-SDRAM
Weight & dimensions:
- Width: 244 mm
- Depth: 244 mm
Network:
- Bluetooth: Yes
- LAN controller: Dragon RTL8125BG
- Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11g, 802.11b, Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 4 (802.11n)
- Ethernet LAN: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Ethernet interface type: 2.5 Gigabit Ethernet
- Bluetooth version: 5.3
- Wi-Fi: Yes
Internal I/O:
- Number of SATA III connectors: 4
- USB 2.0 connectors: 2
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Front panel audio connector: Yes
- TPM connector: Yes
- RGB LED pin header: Yes
Storage controllers:
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- DisplayPorts quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- DisplayPort version: 1.4
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- HDMI ports quantity: 1
- Microphone in: Yes
- Line-in: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- PS/2 ports quantity: 1
Expansion slots:
- Number of M.2 (M) slots: 1
- PCI Express x16 (Gen 5.x) slots: 1
- PCI Express x1 (Gen 4.x) slots: 1
- PCI Express x4 (Gen 1.x) slots: 1
