Leírás és Paraméterek
Processor:
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
- Supported processor sockets: Socket AM5
- Processor manufacturer: AMD
- Processor socket: Socket AM5
Graphics:
- Maximum resolution: 3840 x 2160 pixels
- Parallel processing technology support: Not supported
- HDCP: Yes
Features:
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Motherboard chipset family: AMD
- Audio output channels: 7.1 channels
- Motherboard form factor: micro ATX
- Motherboard chipset: AMD B850
- Product colour: Black
- Audio chip: Realtek ALC897
Memory:
- Number of memory slots: 2
- ECC сompatibility: ECC & Non-ECC
- Supported memory types: DDR5-SDRAM
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Maximum internal memory: 128 GB
Weight & dimensions:
- Depth: 226 mm
- Width: 244 mm
Network:
- MU-MIMO: Yes
- Wi-Fi: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- Ethernet LAN: Yes
- Mobile network connection: No
- Bluetooth version: 5.2
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Bluetooth: Yes
- LAN controller: Dragon RTL8125BG
Internal I/O:
- 12V power connector: Yes
- Front panel audio connector: Yes
- EPS power connector (8-pin): Yes
- TPM connector: Yes
- CPU fan connector: Yes
- Number of CPU fan connectors: 2
- Number of SATA III connectors: 4
- Number of EPS power connectors (8-pin): 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- ATX Power connector (24-pin): Yes
- USB Type-C ports quantity: 1
- RGB LED pin header: Yes
- Number of chassis fan connectors: 3
- Number of RGB LED pin headers: 1
- USB 2.0 connectors: 2
Packaging content:
- Screws included: Yes
- Cables included: SATA
Storage controllers:
- RAID levels: 10, 0, 1
- RAID support: Yes
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III
Rear panel I/O ports:
- Line-in: Yes
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- DisplayPort version: 1.4
- Audio output: 3.5 mm
- HDMI version: 2.1
- Ethernet LAN (RJ-45) ports: 1
- Microphone in: Yes
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- DisplayPorts quantity: 1
Expansion slots:
- Number of M.2 (M) slots: 2
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (E) slots: 1
- PCI Express x16 (Gen 5.x) slots: 1
- PCI Express x1 (Gen 4.x) slots: 1
- 2nd M.2 largest key size: 2280
- 1st M.2 largest key size: 2280
- 1st M.2 highest PCI Express generation: 5.0
- 2nd M.2 highest PCI Express generation: 4.0
