Processor:
- Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5
- Maximum number of SMP processors: 1
- Processor manufacturer: Intel
- Processor socket: LGA 1700
Features:
- Audio output channels: 7.1 channels
- Motherboard chipset: Intel Z790
- Motherboard form factor: ATX
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Audio chip: Realtek ALC897
- Motherboard chipset family: Intel
Memory:
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Unbuffered memory: Yes
- Supported memory types: DDR5-SDRAM
- Maximum internal memory: 128 GB
- Number of memory slots: 4
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Width: 305 mm
- Depth: 244 mm
Network:
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- LAN controller: Dragon RTL8125BG
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Wi-Fi standards: Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), 802.11g, 802.11a, Wi-Fi 5 (802.11ac)
- Ethernet interface type: 2.5 Gigabit Ethernet
- Bluetooth: Yes
Internal I/O:
- Thunderbolt headers: 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- CPU fan connector: Yes
- ATX Power connector (24-pin): Yes
- USB 2.0 connectors: 2
- Front panel audio connector: Yes
- TPM connector: Yes
- Number of SATA III connectors: 8
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- RGB LED pin header: Yes
Storage controllers:
- RAID support: Yes
- Supported storage drive types: HDD & SSD
- RAID levels: 1, 10, 0, 5
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- DisplayPorts quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- HDMI ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- DisplayPort version: 1.4
- Headphone outputs: 1
- Microphone in: Yes
- S/PDIF out port: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 8
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x16 (Gen 3.x) slots: 1
- Number of M.2 (M) slots: 1
- PCI Express x16 (Gen 5.x) slots: 1
