Leírás és Paraméterek
Processor:
- Processor manufacturer: AMD
- Compatible processor series: AMD Ryzen 7000 Series
- Processor socket: Socket AM5
- Supported processor sockets: Socket AM5
Features:
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 10 x64, Windows 11
- Motherboard chipset: AMD A620
- Motherboard chipset family: AMD
- Motherboard form factor: micro ATX
Memory:
- Supported memory clock speed (max): 6400 MHz
- Supported memory clock speeds: 5600, 6200, 6000, 6400, 5800, 5400, 4800, 5000, 5200
- Memory channels: Dual-channel
- Unbuffered memory: Yes
- ECC сompatibility: Non-ECC
- Number of memory slots: 4
- Memory slots type: DIMM
- Maximum internal memory: 128 GB
- Supported memory types: DDR5-SDRAM
Weight & dimensions:
- Height: 43 mm
- Width: 244 mm
- Depth: 244 mm
Network:
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
- Wi-Fi: No
Internal I/O:
- S/PDIF out connector: Yes
- Number of SATA III connectors: 4
- RGB LED pin header: Yes
- EPS power connector (8-pin): Yes
- TPM connector: Yes
- Front panel connector: Yes
- Number of chassis fan connectors: 2
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- USB 2.0 connectors: 2
- Front panel audio connector: Yes
- Number of COM connectors: 1
- 12V power connector: Yes
Packaging data:
- Package weight: 1.36 kg
- Package height: 67.5 mm
- Package width: 275 mm
- Package depth: 275 mm
Storage controllers:
- RAID levels: 10, 0, 1
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- Number of storage drives supported: 6
- Number of HDDs supported: 4
- RAID support: Yes
Rear panel I/O ports:
- Headphone outputs: 1
- DisplayPorts quantity: 1
- Line-in: Yes
- HDMI ports quantity: 1
- VGA (D-Sub) ports quantity: 1
- Microphone in: Yes
- PS/2 ports quantity: 1
- USB 2.0 ports quantity: 4
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x1 (Gen 3.x) slots: 2
- Number of M.2 (M) slots: 2
