Leírás és Paraméterek
Processor:
- Processor manufacturer: AMD
- Processor socket: Socket AM5
- Compatible processor series: AMD Ryzen 7000 Series
- Supported processor sockets: Socket AM5
Features:
- Audio output channels: 7.1 channels
- Motherboard form factor: micro ATX
- Component for: PC
- Windows operating systems supported: Windows 11, Windows 10 x64
- Motherboard chipset: AMD B650
- Motherboard chipset family: AMD
Memory:
- Supported memory types: DDR5-SDRAM
- Supported memory clock speed (max): 6400 MHz
- Number of memory slots: 2
- Memory slots type: DIMM
- Unbuffered memory: Yes
- Memory channels: Dual-channel
- Supported memory clock speeds: 6000, 5200 MHz, 4800, 5600, 6200, 6400, 5800, 5400, 5000
- Maximum internal memory: 96 GB
- ECC сompatibility: ECC & Non-ECC
Weight & dimensions:
- Depth: 221 mm
- Width: 244 mm
Network:
- Ethernet LAN: Yes
- Wi-Fi: No
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- RGB LED pin header: Yes
- 12V power connector: Yes
- Audio connector: Yes
- Number of COM connectors: 1
- S/PDIF out connector: Yes
- TPM connector: Yes
- EPS power connector (8-pin): Yes
- Front panel audio connector: Yes
- CPU fan connector: Yes
- ATX Power connector (24-pin): Yes
- USB 2.0 connectors: 2
- Number of chassis fan connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Number of SATA III connectors: 4
BIOS:
- BIOS type: UEFI AMI
- BIOS memory size: 256 Mbit
Packaging data:
- Package depth: 270 mm
- Package weight: 1.07 kg
- Package height: 51.5 mm
- Package width: 260 mm
Storage controllers:
- Number of HDDs supported: 4
- Number of storage drives supported: 6
- RAID levels: 1, 10, 0
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
- Supported storage drive types: HDD & SSD
Rear panel I/O ports:
- Microphone in: Yes
- Line-in: Yes
- VGA (D-Sub) ports quantity: 1
- PS/2 ports quantity: 1
- Headphone outputs: 1
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- USB 2.0 ports quantity: 4
- HDMI ports quantity: 1
Expansion slots:
- PCI Express x1 (Gen 4.x) slots: 2
- PCI Express x16 (Gen 4.x) slots: 2
- Number of M.2 (M) slots: 2
