Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Core™ i3, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i5, Intel® Celeron®
- Supported processor sockets: LGA 1700
- Processor manufacturer: Intel
- Processor socket: LGA 1700
Features:
- Audio output channels: 7.1 channels
- Motherboard form factor: micro ATX
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Motherboard chipset family: Intel
- Motherboard chipset: Intel B660
Memory:
- Memory slots type: DIMM
- Supported memory types: DDR4-SDRAM
- Supported memory clock speeds: 2133, 3333, 3466, 3400, 4600, 4000, 4800, 3000, 5333 MHz, 3733, 4400, 5000, 3200, 2666, 4266, 2400, 2800, 2933, 3600
- Maximum internal memory: 64 GB
- Memory channels: Dual-channel
- Unbuffered memory: Yes
- Number of memory slots: 2
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Width: 244 mm
- Height: 60 mm
- Depth: 211 mm
Network:
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
- Wi-Fi: No
Internal I/O:
- S/PDIF out connector: Yes
- Number of SATA III connectors: 4
- CPU fan connector: Yes
- EPS power connector (8-pin): Yes
- RGB LED pin header: Yes
- ATX Power connector (24-pin): Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Front panel connector: Yes
- TPM connector: Yes
- USB 2.0 connectors: 2
- Audio connector: Yes
- Front panel audio connector: Yes
- Number of COM connectors: 1
- Number of chassis fan connectors: 1
BIOS:
- Clear CMOS jumper: Yes
- BIOS type: UEFI AMI
Storage controllers:
- RAID levels: 10, 0, 5, 1
- Number of HDDs supported: 4
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
- RAID support: Yes
- Number of storage drives supported: 6
Rear panel I/O ports:
- HDMI version: 2.1
- USB 2.0 ports quantity: 2
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- VGA (D-Sub) ports quantity: 1
- Headphone outputs: 3
- Ethernet LAN (RJ-45) ports: 1
- PS/2 ports quantity: 1
Expansion slots:
- PCI Express x1 (Gen 3.x) slots: 2
- PCI Express x16 (Gen 4.x) slots: 1
