Leírás és Paraméterek
Processor:
- Processor socket: LGA 1700
- Maximum number of SMP processors: 1
- Supported processor sockets: LGA 1700
- Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3
- Processor manufacturer: Intel
Features:
- Power source type: ATX
- Windows operating systems supported: Windows 11, Windows 10
- Audio output channels: 7.1 channels
- Motherboard chipset family: Intel
- Motherboard form factor: ATX
- Cooling type: Passive
- Motherboard chipset: Intel B760
Memory:
- Memory channels: Dual-channel
- Supported memory types: DDR4-SDRAM
- Memory slots type: DIMM
- Number of memory slots: 4
- Supported memory clock speed (max): 5066 MHz
- ECC сompatibility: Non-ECC
- Supported memory clock speeds: 2400, 2800, 5066, 4600, 3000, 3333, 4000, 4800, 2133, 3466, 2933, 3600, 3400, 3733, 4400, 5000, 3200, 2666, 4266
- Maximum internal memory: 128 GB
- Unbuffered memory: Yes
Weight & dimensions:
- Depth: 244 mm
- Width: 305 mm
Network:
- Ethernet interface type: 2.5 Gigabit Ethernet
- Ethernet LAN: Yes
- Wi-Fi: No
Internal I/O:
- USB 2.0 connectors: 2
- Peripheral (Molex) power connectors (4-pin): 1
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- Front panel connector: Yes
- CPU fan connector: Yes
- RGB LED pin header: Yes
- TPM connector: Yes
- Thunderbolt headers: 1
- EPS power connector (8-pin): Yes
- Number of COM connectors: 1
- Number of SATA III connectors: 4
- 12V power connector: Yes
- Number of chassis fan connectors: 3
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- S/PDIF out connector: Yes
Packaging data:
- Package weight: 1.16 kg
- Package depth: 266 mm
- Package height: 53 mm
- Package width: 328 mm
Packaging content:
- User guide: Yes
- Cables included: SATA
Storage controllers:
- RAID levels: 10, 5, 0, 1
- Number of storage drives supported: 7
- Number of HDDs supported: 4
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
- Supported storage drive types: HDD & SSD
Rear panel I/O ports:
- Line-in: Yes
- HDMI version: 2.1
- DisplayPort version: 1.4
- HDMI ports quantity: 1
- DisplayPorts quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- Ethernet LAN (RJ-45) ports: 1
- Headphone outputs: 1
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- VGA (D-Sub) ports quantity: 1
- USB 2.0 ports quantity: 2
Expansion slots:
- PCI Express x1 (Gen 3.x) slots: 2
- Number of M.2 (M) slots: 3
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x16 (Gen 5.x) slots: 1
