Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
- Processor manufacturer: Intel
- Supported processor sockets: LGA 1700
- Maximum number of SMP processors: 1
- Processor socket: LGA 1700
Features:
- Windows operating systems supported: Windows 11, Windows 10 x64
- Audio output channels: 7.1 channels
- Motherboard form factor: ATX
- Cooling type: Passive
- Motherboard chipset family: Intel
- Motherboard chipset: Intel B760
- Power source type: ATX
Memory:
- ECC сompatibility: Non-ECC
- Unbuffered memory: Yes
- Memory channels: Dual-channel
- Supported memory clock speeds: 6800, 6200, 5800, 5400, 7000, 5000, 5200, 6600, 6000, 6400, 5600, 7200, 4800
- Maximum internal memory: 192 GB
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- Number of memory slots: 4
Weight & dimensions:
- Depth: 244 mm
- Height: 36 mm
- Width: 305 mm
Network:
- Ethernet interface type: 2.5 Gigabit Ethernet, Gigabit Ethernet, Fast Ethernet
- Ethernet LAN: Yes
- Wi-Fi: No
Internal I/O:
- Thunderbolt headers: 1
- Front panel audio connector: Yes
- Peripheral (Molex) power connectors (4-pin): 1
- Number of COM connectors: 1
- EPS power connector (8-pin): Yes
- Front panel connector: Yes
- TPM connector: Yes
- Number of SATA III connectors: 4
- CPU fan connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- S/PDIF out connector: Yes
- USB 2.0 connectors: 2
- ATX Power connector (24-pin): Yes
- Number of chassis fan connectors: 3
- RGB LED pin header: Yes
- 12V power connector: Yes
Packaging data:
- Package weight: 1.2 kg
- Package depth: 266 mm
- Package width: 328 mm
- Package height: 53 mm
Storage controllers:
- RAID levels: 10, 1, 0, 5
- Number of storage drives supported: 7
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- RAID support: Yes
- Number of HDDs supported: 4
Rear panel I/O ports:
- USB 2.0 ports quantity: 2
- HDMI version: 2.1
- Ethernet LAN (RJ-45) ports: 1
- DisplayPorts quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- DisplayPort version: 1.4
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
- Headphone outputs: 1
- Line-in: Yes
- VGA (D-Sub) ports quantity: 1
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
Expansion slots:
- Number of M.2 (M) slots: 3
- PCI Express x1 (Gen 3.x) slots: 2
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x16 (Gen 5.x) slots: 1
