Leírás és Paraméterek
Processor:
- Supported processor sockets: LGA 1700
- Processor socket: LGA 1700
- Compatible processor series: Intel® Core™ i3, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i5, Intel® Celeron®
- Processor manufacturer: Intel
Features:
- Motherboard form factor: micro ATX
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 10 x64, Windows 11
- Motherboard chipset family: Intel
- Motherboard chipset: Intel B760
Memory:
- Supported memory types: DDR4-SDRAM
- Memory slots type: DIMM
- Supported memory clock speed (max): 5333 MHz
- Memory channels: Dual-channel
- Number of memory slots: 4
- Supported memory clock speeds: 3333, 4600, 3400, 3000, 5333 MHz, 4000, 4800, 2400, 2800, 5066, 2133, 3466, 3200, 2666, 4266, 2933, 3600, 3733, 4400, 5000
- Maximum internal memory: 128 GB
- ECC сompatibility: Non-ECC
- Unbuffered memory: Yes
Weight & dimensions:
- Width: 244 mm
- Depth: 244 mm
Network:
- Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, 802.11b, Wi-Fi 4 (802.11n)
- Ethernet LAN: Yes
- Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
- Ethernet interface type: 2.5 Gigabit Ethernet
- Bluetooth version: 5.2
- Wi-Fi: Yes
- Bluetooth: Yes
Internal I/O:
- RGB LED pin header: Yes
- ATX Power connector (24-pin): Yes
- Number of SATA III connectors: 4
- Number of chassis fan connectors: 2
- USB 2.0 connectors: 3
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
- EPS power connector (8-pin): Yes
- TPM connector: Yes
- CPU fan connector: Yes
- Front panel audio connector: Yes
- Number of COM connectors: 1
- S/PDIF out connector: Yes
- 12V power connector: Yes
BIOS:
- Clear CMOS button: Yes
- BIOS type: UEFI AMI
Packaging data:
- Package weight: 1.4 kg
- Package depth: 275 mm
- Package height: 67.5 mm
- Package width: 275 mm
Storage controllers:
- RAID levels: 0, 10, 5, 1
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- Number of storage drives supported: 6
- RAID support: Yes
Rear panel I/O ports:
- Headphone outputs: 3
- DisplayPorts quantity: 1
- DisplayPort version: 1.4
- HDMI version: 2.1
- HDMI ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- USB 2.0 ports quantity: 4
- Line-in: Yes
- Ethernet LAN (RJ-45) ports: 1
- Microphone in: Yes
- PS/2 ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 3
- Number of M.2 (M) slots: 2
