Leírás és Paraméterek
Processor:
- Processor socket: LGA 1700
- Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3
- Supported processor sockets: LGA 1700
- Processor manufacturer: Intel
Features:
- Audio output channels: 7.1 channels
- Motherboard chipset family: Intel
- Motherboard chipset: Intel B760
- Motherboard form factor: micro ATX
- Windows operating systems supported: Windows 10 x64, Windows 11
Memory:
- Unbuffered memory: Yes
- Supported memory clock speeds: 3733, 4400, 5000, 4000, 4800, 4600, 2400, 2800, 5066, 3200, 2666, 4266, 3000, 5333 MHz, 2133, 3466, 3400, 3333, 2933, 3600
- Maximum internal memory: 64 GB
- Number of memory slots: 2
- Memory slots type: DIMM
- Supported memory types: DDR4-SDRAM
- Supported memory clock speed (max): 5333 MHz
- Memory channels: Dual-channel
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Depth: 211 mm
- Height: 36 mm
- Width: 244 mm
Network:
- Wake-on-LAN ready: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- Ethernet LAN: Yes
- Wi-Fi: No
Internal I/O:
- USB 2.0 connectors: 2
- Number of SATA III connectors: 4
- S/PDIF out connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- RGB LED pin header: Yes
- Front panel audio connector: Yes
- 12V power connector: Yes
- Number of chassis fan connectors: 1
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- Number of COM connectors: 1
- TPM connector: Yes
- EPS power connector (8-pin): Yes
Packaging data:
- Package weight: 926.3 g
- Package depth: 51.5 mm
- Package height: 263 mm
- Package width: 270 mm
Storage controllers:
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- Number of HDDs supported: 4
- RAID support: Yes
- RAID levels: 0, 10, 1, 5
- Number of storage drives supported: 6
Rear panel I/O ports:
- VGA (D-Sub) ports quantity: 1
- USB 2.0 ports quantity: 2
- HDMI ports quantity: 1
- Microphone in: Yes
- Ethernet LAN (RJ-45) ports: 1
- PS/2 ports quantity: 1
- USB connector type: USB Type-A
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Expansion slots:
- PCI Express x1 (Gen 4.x) slots: 2
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 2
