Leírás és Paraméterek
Processor:
- Processor socket: LGA 1200 (Socket H5)
- Compatible processor series: Intel® Core™ i3, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i5, Intel® Celeron®
- Processor manufacturer: Intel
- Supported processor sockets: LGA 1200 (Socket H5)
Features:
- Motherboard chipset: Intel H510
- Motherboard chipset family: Intel
- Motherboard form factor: micro ATX
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 10 x64
Memory:
- Supported memory clock speed (max): 3200 MHz
- Supported memory types: DDR4-SDRAM
- Number of memory slots: 2
- Memory slots type: DIMM
- Supported memory clock speeds: 3000, 3200, 2666, 2400, 2800, 2133, 2933
- Unbuffered memory: Yes
- Maximum internal memory: 64 GB
- Memory channels: Dual-channel
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Depth: 211 mm
- Width: 226 mm
Network:
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
- Wi-Fi: No
Internal I/O:
- RGB LED pin header: Yes
- Audio connector: Yes
- 12V power connector: Yes
- ATX Power connector (24-pin): Yes
- Number of SATA III connectors: 4
- S/PDIF out connector: Yes
- EPS power connector (8-pin): Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- TPM connector: Yes
- Number of COM connectors: 1
- USB 2.0 connectors: 3
- CPU fan connector: Yes
- Number of chassis fan connectors: 2
- Front panel audio connector: Yes
Packaging data:
- Package depth: 270 mm
- Package height: 51.5 mm
- Package width: 260 mm
- Package weight: 1.03 kg
Storage controllers:
- Number of HDDs supported: 4
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- Number of storage drives supported: 5
Rear panel I/O ports:
- Headphone outputs: 1
- VGA (D-Sub) ports quantity: 1
- Line-in: Yes
- DisplayPorts quantity: 1
- USB 2.0 ports quantity: 2
- Microphone in: Yes
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- HDMI ports quantity: 1
- PS/2 ports quantity: 2
Expansion slots:
- Number of M.2 (M) slots: 1
- PCI Express x1 (Gen 3.x) slots: 2
