Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5, Intel® Celeron®, Intel Pentium G, Intel® Core™ i3
- Processor manufacturer: Intel
- Supported processor sockets: LGA 1700
- Processor socket: LGA 1700
Graphics:
- Parallel processing technology support: Not supported
- Maximum resolution: 3840 x 2160 pixels
Features:
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Motherboard chipset family: Intel
- Audio output channels: 7.1 channels
- Motherboard form factor: micro ATX
- Motherboard chipset: Intel H610
Memory:
- Memory slots type: DIMM
- Supported memory types: DDR4-SDRAM
- Supported memory clock speeds: 3000, 2933, 3200, 2666, 2133, 2400, 2800
- Maximum internal memory: 64 GB
- Unbuffered memory: Yes
- Memory channels: Dual-channel
- Number of memory slots: 2
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Height: 51 mm
- Depth: 193 mm
- Width: 226 mm
Network:
- Wi-Fi: No
- Wake-on-LAN ready: Yes
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
Internal I/O:
- 12V power connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- CPU fan connector: Yes
- Front panel audio connector: Yes
- Number of COM connectors: 1
- USB 2.0 connectors: 2
- ATX Power connector (24-pin): Yes
- Chassis intrusion connector: Yes
- Number of SATA III connectors: 4
- Audio connector: Yes
- Number of chassis fan connectors: 1
- TPM connector: Yes
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS jumper: Yes
Packaging content:
- Cables included: SATA
- Drivers included: Yes
Storage controllers:
- Number of storage drives supported: 5
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- HDMI version: 2.1
- Ethernet LAN (RJ-45) ports: 1
- PS/2 ports quantity: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- HDMI ports quantity: 1
- Microphone in: Yes
- DVI-D ports quantity: 1
- USB 2.0 ports quantity: 2
- USB connector type: USB Type-A
- Headphone outputs: 3
- VGA (D-Sub) ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 1
- PCI Express x1 (Gen 3.x) slots: 1
