Leírás és Paraméterek
Processor:
- Processor manufacturer: AMD
- Processor socket: Socket AM5
Features:
- Audio output channels: 7.1 channels
- Motherboard chipset family: AMD
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Motherboard form factor: ATX
- Motherboard chipset: AMD X670
Memory:
- Memory channels: Dual-channel
- Supported memory clock speeds: 5100, 6400, 5600, 6000, 6200, 4800, 5800, 5400, 5200
- Unbuffered memory: Yes
- Memory slots type: DIMM
- ECC сompatibility: ECC & Non-ECC
- Number of memory slots: 4
- Supported memory types: DDR5-SDRAM
- Maximum internal memory: 128 GB
Weight & dimensions:
- Width: 305 mm
- Depth: 244 mm
Network:
- Wi-Fi standards: 802.11g, 802.11b, Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n)
- Ethernet LAN: Yes
- Ethernet interface type: Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet
- Bluetooth: Yes
- Wi-Fi: Yes
- Bluetooth version: 5.2
- Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Internal I/O:
- ATX Power connector (24-pin): Yes
- TPM connector: Yes
- EPS power connector (8-pin): Yes
- Number of chassis fan connectors: 3
- Thunderbolt headers: 1
- Peripheral (Molex) power connectors (4-pin): 1
- USB 2.0 connectors: 2
- Number of SATA III connectors: 6
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
- S/PDIF out connector: Yes
- CPU fan connector: Yes
- Front panel audio connector: Yes
- Number of COM connectors: 1
Packaging data:
- Package weight: 1.9 kg
- Package width: 338 mm
- Package depth: 68 mm
- Package height: 273 mm
Storage controllers:
- RAID levels: 10, 0, 1
- RAID support: Yes
- Number of storage drives supported: 9
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- DisplayPorts quantity: 1
- HDMI ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- PS/2 ports quantity: 1
Expansion slots:
- Number of M.2 (M) slots: 3
- PCI Express x16 (Gen 4.x) slots: 3
- PCI Express x1 (Gen 3.x) slots: 1
