Leírás és Paraméterek
Processor:
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
- Processor manufacturer: AMD
- Supported processor sockets: Socket AM5
- Processor socket: Socket AM5
Graphics:
- On-board graphics card: No
- Parallel processing technology support: Not supported
Features:
- Product colour: Black
- Motherboard chipset: AMD X870
- Motherboard chipset family: AMD
- Audio output channels: 7.1 channels
- Cooling type: Passive
- Windows operating systems supported: Windows 11, Windows 10
- Motherboard form factor: ATX
- Power source type: ATX
Memory:
- Unbuffered memory: Yes
- Memory slots type: DIMM
- Maximum internal memory: 192 GB
- Number of memory slots: 4
- Supported memory types: DDR5-SDRAM
- Memory channels: Dual-channel
- Supported memory clock speed (max): 8000 MHz
- ECC сompatibility: ECC & Non-ECC
Weight & dimensions:
- Height: 48 mm
- Depth: 244 mm
- Width: 305 mm
Network:
- Ethernet LAN: Yes
- Wi-Fi: No
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- USB 2.0 connectors: 2
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- Front panel audio connector: Yes
- 12V power connector: Yes
- RGB LED pin header: Yes
- ATX Power connector (24-pin): Yes
- Number of COM connectors: 1
- CPU fan connector: Yes
- Number of SATA III connectors: 2
- Number of chassis fan connectors: 4
- TPM connector: Yes
- EPS power connector (8-pin): Yes
Packaging data:
- Package height: 68 mm
- Package width: 353 mm
- Package depth: 273 mm
- Package weight: 1.5 kg
Storage controllers:
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- RAID levels: 10, 0, 5, 1
- RAID support: Yes
- Number of HDDs supported: 2
- Number of storage drives supported: 6
Rear panel I/O ports:
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- HDMI version: 2.1
- USB 2.0 ports quantity: 4
- DisplayPort version: 1.4a
- Microphone in: Yes
- Ethernet LAN (RJ-45) ports: 1
- Line-in: Yes
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- USB4 Gen 2x2 ports quantity: 2
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 2
- Number of M.2 (M) slots: 4
- PCI Express x16 (Gen 5.x) slots: 1
Other features:
- Weight: 1.44 kg
- Back-to-BIOS button: Yes
