Leírás és Paraméterek
Processor:
- Supported processor sockets: LGA 1700
- Processor manufacturer: Intel
- Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
- Maximum number of SMP processors: 1
- Processor socket: LGA 1700
Graphics:
- On-board graphics card: No
- Parallel processing technology support: Not supported
Features:
- Motherboard form factor: ATX
- Component for: PC
- Cooling type: Passive
- Audio output channels: 7.1 channels
- Motherboard chipset family: Intel
- Windows operating systems supported: Windows 11, Windows 10 x64
- Product colour: Black
- Motherboard chipset: Intel W680
- Power source type: ATX
Memory:
- Maximum internal memory: 128 GB
- Memory channels: Dual-channel
- Unbuffered memory: Yes
- Number of memory slots: 4
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- ECC сompatibility: ECC & Non-ECC
Weight & dimensions:
- Width: 305 mm
- Depth: 244 mm
- Height: 50 mm
Network:
- Ethernet interface type: 2.5 Gigabit Ethernet
- Wi-Fi: No
- Ethernet LAN: Yes
Internal I/O:
- Number of COM connectors: 1
- Number of SATA III connectors: 4
- EPS power connector (8-pin): Yes
- TPM connector: Yes
- Peripheral (Molex) power connectors (4-pin): 1
- CPU fan connector: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- Front panel audio connector: Yes
- Thunderbolt headers: 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- ATX Power connector (24-pin): Yes
- Number of chassis fan connectors: 3
- USB 2.0 connectors: 2
- 12V power connector: Yes
- Integrated SAS ports: 1
BIOS:
- BIOS memory size: 256 Mbit
- BIOS type: UEFI AMI
Packaging data:
- Package height: 76 mm
- Package width: 331 mm
- Package weight: 1.18 kg
- Package depth: 266 mm
Packaging content:
- Cables included: SATA
- User guide: Yes
Storage controllers:
- RAID levels: 1, 0, 10, 5
- Supported storage drive interfaces: M.2, NVMe, SATA III
- Number of storage drives supported: 11
- Supported storage drive types: HDD & SSD
- RAID support: Yes
- Number of HDDs supported: 8
Rear panel I/O ports:
- DisplayPorts quantity: 1
- USB 2.0 ports quantity: 2
- Ethernet LAN (RJ-45) ports: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- HDMI version: 2.1
- Microphone in: Yes
- DisplayPort version: 1.4
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- VGA (D-Sub) ports quantity: 1
- Line-in: Yes
Expansion slots:
- PCI Express x16 (Gen 3.x) slots: 2
- PCI Express x1 (Gen 3.x) slots: 1
- Number of M.2 (M) slots: 3
Other features:
- Weight: 997 g
- Back-to-BIOS button: Yes
- Number of M.2 (E) slots: 1
