Processor:
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
- Processor manufacturer: AMD
- Supported processor sockets: Socket AM5
- Processor socket: Socket AM5
Graphics:
- On-board graphics card: No
- Parallel processing technology support: Not supported
Features:
- Motherboard form factor: ATX
- Motherboard chipset family: AMD
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 11
- Product colour: Black
- Motherboard chipset: AMD X870E
Memory:
- ECC сompatibility: ECC & Non-ECC
- Memory slots type: DIMM
- Maximum internal memory: 128 GB
- Number of memory slots: 2
- Supported memory types: DDR5-SDRAM
- Memory channels: Dual-channel
- Unbuffered memory: Yes
Weight & dimensions:
- Depth: 244 mm
- Width: 305 mm
Network:
- Bluetooth version: 5.4
- Ethernet LAN: Yes
- Ethernet interface type: 5 Gigabit Ethernet
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- Wi-Fi standards: Wi-Fi 7 (802.11be)
- Bluetooth: Yes
- Wi-Fi: Yes
Internal I/O:
- RGB LED pin header: Yes
- 12V power connector: Yes
- USB 3.2 Gen 2x2 connectors: 2
- Number of RGB LED pin headers: 3
- Front panel audio connector: Yes
- CPU fan connector: Yes
- USB 2.0 connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Number of SATA III connectors: 4
- ATX Power connector (24-pin): Yes
- EPS power connector (8-pin): Yes
- Front panel connector: Yes
- Number of chassis fan connectors: 2
Packaging data:
- Package weight: 4.16 kg
- Package width: 370 mm
- Package depth: 312 mm
- Package height: 108 mm
Packaging content:
- Antenna included: Yes
- Drivers included: Yes
- Cables included: SATA
- Screws included: Yes
Storage controllers:
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- RAID levels: 1, 5, 0, 10
- Number of storage drives supported: 9
- Number of HDDs supported: 4
- RAID support: Yes
Rear panel I/O ports:
- WiFi-AP antenna jack: 1
- USB4 Gen 3x2 ports quantity: 2
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 5
- PS/2 ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- S/PDIF out port: Yes
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 2
- PCI Express x4 (Gen 4.x) slots: 1
- 2nd M.2 highest PCI Express generation: 5.0
- 1st M.2 largest key size: 2280
- 3rd M.2 highest PCI Express generation: 5.0
- PCI Express x16 (Gen 5.x) slots: 2
- 4th M.2 largest key size: 22110
- 2nd M.2 largest key size: 2280
- 4th M.2 highest PCI Express generation: 4.0
- 3rd M.2 largest key size: 2280
- 1st M.2 highest PCI Express generation: 5.0
- 5th M.2 largest key size: 22110
- 5th M.2 highest PCI Express generation: 4.0
- Number of M.2 (M) slots: 5
- PCI Express x1 (Gen 3.x) slots: 1
