Leírás és Paraméterek
Processor:
- Processor socket: Socket AM5
- Supported processor sockets: Socket AM5
- Processor manufacturer: AMD
Features:
- Motherboard chipset: AMD X870E
- Motherboard chipset family: AMD
- Motherboard form factor: ATX
- Audio output channels: 7.1 channels
- Audio chip: Realtek ALC4082
- Windows operating systems supported: Windows 11
Memory:
- Memory channels: Dual-channel
- Unbuffered memory: Yes
- Supported memory types: DDR5-SDRAM
- Number of memory slots: 4
- Maximum internal memory: 192 GB
- Memory slots type: DIMM
- ECC сompatibility: ECC & Non-ECC
Weight & dimensions:
- Height: 50 mm
- Depth: 244 mm
- Width: 305 mm
Network:
- Bluetooth version: 5.4
- Wi-Fi: Yes
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet, 5 Gigabit Ethernet
- Wi-Fi standards: Wi-Fi 7 (802.11be)
- Bluetooth: Yes
Internal I/O:
- ATX Power connector (24-pin): Yes
- EPS power connector (8-pin): Yes
- Number of SATA III connectors: 4
- USB 2.0 connectors: 2
- Number of chassis fan connectors: 4
- 12V power connector: Yes
- Front panel audio connector: Yes
- CPU fan connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- USB 3.2 Gen 2x2 connectors: 2
BIOS:
- Clear CMOS button: Yes
- BIOS type: UEFI AMI
Packaging data:
- Package weight: 4.26 kg
- Package height: 108 mm
- Package depth: 312 mm
- Package width: 370 mm
Packaging content:
- Drivers included: Yes
- Cables included: SATA
Storage controllers:
- Supported storage drive types: HDD & SSD
- RAID levels: 10, 1, 0, 5
- Number of storage drives supported: 10
- RAID support: Yes
- Number of HDDs supported: 5
- Supported storage drive interfaces: M.2, SATA III, SlimSAS
Rear panel I/O ports:
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
- Ethernet LAN (RJ-45) ports: 2
- Headphone outputs: 1
- Microphone in: Yes
- S/PDIF out port: Yes
- HDMI ports quantity: 1
- WiFi-AP antenna jack: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 6
- USB4 Gen 2x2 ports quantity: 2
Expansion slots:
- Number of M.2 (M) slots: 5
- PCI Express x16 (Gen 4.x) slots: 4
- PCI Express x16 (Gen 5.x) slots: 2
