Leírás és Paraméterek
Processor:
- Supported processor sockets: Socket AM4
- Processor manufacturer: AMD
- Processor socket: Socket AM4
- Compatible processor series: AMD Ryzen 3000 Series
- Maximum number of SMP processors: 1
Graphics:
- On-board graphics card: No
- Parallel processing technology support: 2-Way CrossFireX
Features:
- Component for: PC
- Windows operating systems supported: Windows 10, Windows 10 IOT Core, Windows 10 Pro x64, Windows 10 Enterprise x64, Windows 10 x64, Windows 10 Enterprise, Windows 10 Education x64, Windows 10 Pro, Windows 10 IoT Enterprise, Windows 10 Home, Windows 10 Education, Windows 10 Home x64
- Cooling type: Active
- Power source type: ATX
- Motherboard form factor: ATX
- Motherboard chipset: AMD B550
- PC health monitoring: Fan, CPU
- Audio output channels: 7.1 channels
- Product colour: Black
- Motherboard chipset family: AMD
Memory:
- Memory slots type: DIMM
- Supported memory types: DDR4-SDRAM
- Number of memory slots: 4
- Supported memory clock speeds: 2133, 3466, 3600, 3866, 4400, 4133, 4000, 4600, 3000, 2400, 2800, 3200, 2666
- Maximum internal memory: 128 GB
Weight & dimensions:
- Height: 68 mm
- Width: 305 mm
- Depth: 244 mm
Network:
- Wi-Fi: No
- Ethernet LAN: Yes
- Bluetooth version: 5.0
- Ethernet interface type: 2.5 Gigabit Ethernet
- LAN controller: Intel I225-V
- Bluetooth: Yes
- Wake-on-LAN ready: Yes
Internal I/O:
- EPS power connector (8-pin): Yes
- 12V power connector: Yes
- Number of chassis fan connectors: 3
- CPU fan connector: Yes
- Number of EATX power connectors: 1
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of SATA III connectors: 6
- USB 2.0 connectors: 2
- Thunderbolt headers: 1
BIOS:
- BIOS type: UEFI AMI
- BIOS memory size: 256000 Mbit
Packaging content:
- Drivers included: Yes
- Cables included: SATA
- Manual: Yes
Storage controllers:
- RAID levels: 0, 1, 10
- Number of HDDs supported: 6
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
- Supported storage drive types: HDD & SSD
Rear panel I/O ports:
- HDMI version: 2.1
- Headphone outputs: 1
- HDMI ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- Microphone in: Yes
- Ethernet LAN (RJ-45) ports: 1
- DisplayPort version: 1.2
- S/PDIF out port: Yes
- DisplayPorts quantity: 1
- USB 2.0 ports quantity: 2
Expansion slots:
- Number of M.2 (M) slots: 2
- PCI Express x16 (Gen 3.x) slots: 1
- PCI Express x16 (Gen 4.x) slots: 1
- PCI slots: 7
- PCI Express x1 (Gen 3.x) slots: 3
- PCI Express slots version: 3.0, 4.0
