Leírás és Paraméterek
Processor:
- Compatible processor series: AMD Ryzen™ 7
- Processor manufacturer: AMD
- Processor socket: Socket AM5
- Supported processor sockets: Socket AM5
Graphics:
- On-board graphics card: No
- Parallel processing technology support: Not supported
Features:
- Product colour: Black
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Motherboard chipset family: AMD
- Motherboard chipset: AMD B650
- Motherboard form factor: mini ITX
- Audio chip: Realtek ALC4080
Memory:
- Supported memory clock speeds: 6000, 5000, 4800, 5800, 5400, 6400, 6200, 5600, 5200
- Maximum internal memory: 64 GB
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Number of memory slots: 2
- Unbuffered memory: Yes
- Supported memory types: DDR5-SDRAM
- ECC сompatibility: ECC & Non-ECC
Weight & dimensions:
- Depth: 170 mm
- Width: 170 mm
Network:
- Bluetooth: Yes
- Wi-Fi: Yes
- Ethernet LAN: Yes
- Wi-Fi standards: 802.11b, Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n)
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Bluetooth version: 5.2
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- Number of SATA III connectors: 2
- CPU fan connector: Yes
- Number of chassis fan connectors: 1
- EPS power connector (8-pin): Yes
- ATX Power connector (24-pin): Yes
- RGB LED pin header: Yes
- Audio connector: Yes
- Front panel audio connector: Yes
- USB 2.0 connectors: 2
- 12V power connector: Yes
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS button: Yes
Packaging data:
- Package width: 222 mm
- Package depth: 182 mm
- Package weight: 8.58 kg
- Package height: 92 mm
Storage controllers:
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- RAID levels: 0, 1
- RAID support: Yes
Rear panel I/O ports:
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
- HDMI ports quantity: 1
- Headphone outputs: 1
- S/PDIF out port: Yes
- Microphone in: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- Line-in: Yes
- Ethernet LAN (RJ-45) ports: 1
Expansion slots:
- Number of M.2 (M) slots: 2
- PCI Express x16 (Gen 5.x) slots: 1
