Leírás és Paraméterek
Processor:
- Processor socket: Socket AM5
- Processor manufacturer: AMD
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Supported processor sockets: Socket AM5
Graphics:
- Parallel processing technology support: Not supported
- Maximum resolution: 7680 x 4320 pixels
Features:
- Windows operating systems supported: Windows 11
- Motherboard chipset family: AMD
- Motherboard chipset: AMD B850
- Motherboard form factor: ATX
- Product colour: Black
- Audio chip: Realtek ALC4080
- Audio output channels: 7.1 channels
- Power source type: ATX
Memory:
- Supported memory clock speed (max): 8000 MHz
- Unbuffered memory: Yes
- Supported memory types: DDR5-SDRAM
- Memory slots type: DIMM
- ECC сompatibility: ECC & Non-ECC
- Memory channels: Dual-channel
- Number of memory slots: 4
- Maximum internal memory: 192 GB
Weight & dimensions:
- Depth: 244 mm
- Width: 305 mm
Network:
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- Bluetooth version: 5.4
- Ethernet interface type: 5 Gigabit Ethernet
- Wi-Fi standards: Wi-Fi 7 (802.11be)
- Bluetooth: Yes
Internal I/O:
- Front panel audio connector: Yes
- Front panel connector: Yes
- CPU fan connector: Yes
- Number of SATA III connectors: 4
- Number of water pump connectors: 1
- Number of EPS power connectors (8-pin): 2
- USB 2.0 connectors: 2
- ATX Power connector (24-pin): Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- RGB LED pin header: Yes
- Number of temperature sensor headers: 1
- EPS power connector (8-pin): Yes
- Number of chassis fan connectors: 5
- Number of CPU fan connectors: 2
- Number of RGB LED pin headers: 3
BIOS:
- Clear CMOS button: Yes
- BIOS type: UEFI AMI
Packaging data:
- Package depth: 281 mm
- Package width: 356 mm
- Package height: 87 mm
- Package weight: 2.3 kg
Packaging content:
- Cables included: SATA
- Antenna included: Yes
Storage controllers:
- RAID levels: 10, 1, 0, 5
- Number of storage drives supported: 9
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- Number of HDDs supported: 4
- RAID support: Yes
Rear panel I/O ports:
- DisplayPort version: 1.4
- HDMI version: 2.1
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- WiFi-AP antenna jack: 2
- Digital audio optical out: 1
- Line-in: Yes
- Headphone outputs: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 6
- Ethernet LAN (RJ-45) ports: 1
- HDMI ports quantity: 1
- DisplayPorts quantity: 1
- USB4 Gen 3x2 ports quantity: 1
- S/PDIF out port: Yes
Expansion slots:
- PCI Express x16 (Gen 5.x) slots: 1
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 5
- 2nd M.2 largest key size: 22110
- 3rd M.2 largest key size: 2280
- 1st M.2 largest key size: 2280
- 1st M.2 highest PCI Express generation: 5.0
- 5th M.2 highest PCI Express generation: 4.0
- 2nd M.2 highest PCI Express generation: 5.0
- 3rd M.2 highest PCI Express generation: 5.0
- 4th M.2 highest PCI Express generation: 4.0
- 5th M.2 largest key size: 2280
- 4th M.2 largest key size: 2280
