Leírás és Paraméterek
Processor:
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
- Processor manufacturer: AMD
- Processor socket: Socket AM5
Graphics:
- Parallel processing technology support: Not supported
- On-board graphics card: No
Features:
- Motherboard chipset family: AMD
- Motherboard form factor: mini ITX
- Motherboard chipset: AMD X870
- Product colour: Black
- Windows operating systems supported: Windows 11 x64
Memory:
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- Maximum internal memory: 96 GB
- Memory channels: Dual-channel
- Unbuffered memory: Yes
- Supported memory clock speed (max): 8600 MHz
- Number of memory slots: 2
- ECC сompatibility: ECC & Non-ECC
Weight & dimensions:
- Width: 170 mm
- Depth: 170 mm
Network:
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- Bluetooth: Yes
- Ethernet LAN: Yes
- Wi-Fi standards: Wi-Fi 7 (802.11be)
- Ethernet interface type: Gigabit Ethernet, Fast Ethernet, 2.5 Gigabit Ethernet
- Wi-Fi: Yes
- Bluetooth version: 5.4
Internal I/O:
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- USB 2.0 connectors: 2
- Front panel connector: Yes
- Number of SATA III connectors: 2
- ATX Power connector (24-pin): Yes
- Number of chassis fan connectors: 1
- CPU fan connector: Yes
- EPS power connector (8-pin): Yes
- 12V power connector: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS button: Yes
Storage controllers:
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- RAID support: Yes
- RAID levels: 1, 10, 0
- Number of storage drives supported: 4
- Number of HDDs supported: 2
Rear panel I/O ports:
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB connector type: USB Type-A, USB Type-C
- USB4 Gen 3x2 ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
- USB 2.0 ports quantity: 3
- Ethernet LAN (RJ-45) ports: 1
- HDMI ports quantity: 1
Expansion slots:
- Number of M.2 (M) slots: 2
- PCI Express x16 (Gen 5.x) slots: 1
