Leírás és Paraméterek
Processor:
- Processor manufacturer: AMD
- Processor socket: Socket AM5
- Supported processor sockets: Socket AM5
Graphics:
- Parallel processing technology support: Not supported
- On-board graphics card: No
Features:
- Product colour: Black
- Motherboard chipset: AMD X870E
- Audio output channels: 7.1 channels
- Motherboard chipset family: AMD
- Motherboard form factor: ATX
- Audio chip: Realtek ALC4080
- Windows operating systems supported: Windows 11 x64
Memory:
- Unbuffered memory: Yes
- ECC сompatibility: ECC & Non-ECC
- Number of memory slots: 4
- Memory channels: Dual-channel
- Supported memory types: DDR5-SDRAM
- Maximum internal memory: 192 GB
- Memory slots type: DIMM
Weight & dimensions:
- Width: 305 mm
- Height: 50 mm
- Depth: 244 mm
Network:
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- Bluetooth version: 5.4
- Wi-Fi: Yes
- Ethernet interface type: 5 Gigabit Ethernet
- Wi-Fi standards: Wi-Fi 7 (802.11be)
- Bluetooth: Yes
- Ethernet LAN: Yes
Internal I/O:
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- USB 2.0 connectors: 3
- Number of chassis fan connectors: 5
- 12V power connector: Yes
- USB 3.2 Gen 2x2 connectors: 1
- Front panel audio connector: Yes
- Number of SATA III connectors: 4
BIOS:
- Clear CMOS button: Yes
- BIOS type: UEFI AMI
Packaging data:
- Package width: 365 mm
- Package depth: 281 mm
- Package weight: 3.02 kg
- Package height: 87 mm
Storage controllers:
- Number of HDDs supported: 4
- RAID levels: 0, 5, 1, 10
- RAID support: Yes
- Supported storage drive interfaces: M.2, SATA III
- Number of storage drives supported: 9
- Supported storage drive types: HDD & SSD
Rear panel I/O ports:
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 9
- Microphone in: Yes
- Headphone outputs: 1
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- HDMI ports quantity: 1
- S/PDIF out port: Yes
- USB4 Gen 2x2 ports quantity: 2
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- WiFi-AP antenna jack: 1
Expansion slots:
- PCI Express x16 (Gen 5.x) slots: 1
- Number of M.2 (M) slots: 5
- PCI Express x16 (Gen 4.x) slots: 1
