Leírás és Paraméterek
Processor:
- Supported processor sockets: Socket AM4
- Processor manufacturer: AMD
- Processor socket: Socket AM4
- Compatible processor series: AMD Ryzen 5000 Series, AMD Ryzen 3000 Series
Graphics:
- Maximum resolution: 3840 x 2160 pixels
- Parallel processing technology support: Not supported
Features:
- Motherboard form factor: micro ATX
- Audio output channels: 7.1 channels
- Audio chip: Realtek ALC887 / Realtek ALC897
- Motherboard chipset: AMD A520
- Motherboard chipset family: AMD
- Windows operating systems supported: Windows 10 x64
Memory:
- Supported memory clock speeds: 4600, 3866, 3333, 4466, 2133, 3000, 3466, 3600, 4133, 4000, 4800, 2400, 2800, 3733, 4400 MHz, 3200, 2666, 4266
- Maximum internal memory: 128 GB
- Unbuffered memory: Yes
- Memory channels: Dual-channel
- ECC сompatibility: ECC
- Memory slots type: DIMM
- Supported memory types: DDR4-SDRAM
- Number of memory slots: 4
Weight & dimensions:
- Width: 244 mm
- Height: 67 mm
- Depth: 244 mm
Network:
- Bluetooth: Yes
- Wake-on-LAN ready: Yes
- Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
- Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n)
- Wi-Fi: Yes
- Ethernet LAN: Yes
- WLAN controller model: Realtek RTL8821CE
- Bluetooth version: 5.0
- Ethernet interface type: Gigabit Ethernet
Internal I/O:
- ATX Power connector (24-pin): Yes
- S/PDIF out connector: Yes
- Front panel audio connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- USB 2.0 connectors: 2
- Number of SATA III connectors: 4
- Number of chassis fan connectors: 2
- EPS power connector (8-pin): Yes
- TPM connector: Yes
- CPU fan connector: Yes
- Number of COM connectors: 1
- 12V power connector: Yes
- RGB LED pin header: Yes
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS jumper: Yes
Packaging content:
- Cables included: SATA
- Drivers included: Yes
Storage controllers:
- Supported storage drive interfaces: M.2, PCI Express 3.0, SATA III
- Supported storage drive types: HDD & SSD
- RAID levels: 10, 0, 1
- Number of storage drives supported: 5
Rear panel I/O ports:
- DisplayPort version: 1.2
- Ethernet LAN (RJ-45) ports: 1
- USB connector type: USB Type-A
- USB 2.0 ports quantity: 2
- DisplayPorts quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- HDMI version: 2.1
- PS/2 ports quantity: 1
- HDMI ports quantity: 1
- VGA (D-Sub) ports quantity: 1
- Microphone in: Yes
- WiFi-AP antenna jack: 1
- Headphone outputs: 3
Expansion slots:
- PCI Express x16 (Gen 3.x) slots: 1
- PCI Express x1 (Gen 3.x) slots: 2
- Number of M.2 (M) slots: 1
