Leírás és Paraméterek
Processor:
- Processor manufacturer: AMD
- Compatible processor series: AMD Ryzen 7000 Series
- Supported processor sockets: Socket AM5
- Processor socket: Socket AM5
Features:
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 10, Windows 11 x64
- Power source type: ATX
- Motherboard chipset family: AMD
- Motherboard chipset: AMD B650
- Motherboard form factor: ATX
Memory:
- Supported memory clock speeds: 5800, 5400, 5600, 6400, 6000, 5000, 6200, 4800, 5200
- Unbuffered memory: Yes
- Memory channels: Dual-channel
- Maximum internal memory: 128 GB
- Number of memory slots: 4
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- ECC сompatibility: ECC & Non-ECC
- Supported memory clock speed (max): 6400 MHz
Weight & dimensions:
- Depth: 244 mm
- Width: 305 mm
Network:
- Ethernet interface type: 2.5 Gigabit Ethernet
- Ethernet LAN: Yes
- Wi-Fi: No
Internal I/O:
- CPU fan connector: Yes
- ATX Power connector (24-pin): Yes
- Thunderbolt headers: 1
- Number of SATA III connectors: 4
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- RGB LED pin header: Yes
- EPS power connector (8-pin): Yes
- Number of chassis fan connectors: 4
- Front panel audio connector: Yes
- Number of COM connectors: 1
- 12V power connector: Yes
- USB 2.0 connectors: 2
Packaging data:
- Package height: 68 mm
- Package weight: 1.36 kg
- Package width: 338 mm
- Package depth: 273 mm
Storage controllers:
- RAID levels: 0, 10, 1
- Supported storage drive types: HDD & SSD
- RAID support: Yes
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- HDMI ports quantity: 1
- HDMI version: 2.1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- DisplayPorts quantity: 1
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- Line-in: Yes
- DisplayPort version: 1.4
- USB 2.0 ports quantity: 4
- Headphone outputs: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- Microphone in: Yes
- Ethernet LAN (RJ-45) ports: 1
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 2
- PCI Express x4 (Gen 1.x) slots: 2
- Number of M.2 (M) slots: 3
