Leírás és Paraméterek
Processor:
- Processor manufacturer: AMD
- Processor socket: Socket AM5
- Compatible processor series: AMD Ryzen 7000 Series
- Supported processor sockets: Socket AM5
Graphics:
- Parallel processing technology support: Not supported
- On-board graphics card: No
Features:
- Product colour: Black
- Motherboard chipset family: AMD
- Motherboard form factor: ATX
- Audio output channels: 7.1 channels
- Motherboard chipset: AMD B650
Memory:
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Unbuffered memory: Yes
- Supported memory types: DDR5-SDRAM
- Supported memory clock speeds: 5000, 7600, 6200, 5800, 5400, 6400, 5200, 6000, 6600, 7000, 6800, 5600, 7200, 4800
- ECC сompatibility: ECC & Non-ECC
- Number of memory slots: 4
- Maximum internal memory: 128 GB
Weight & dimensions:
- Depth: 244 mm
- Height: 50 mm
- Width: 305 mm
Network:
- Ethernet LAN: Yes
- Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), 802.11g, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
- Wi-Fi: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
- Bluetooth: Yes
- Bluetooth version: 5.2
Internal I/O:
- EPS power connector (8-pin): Yes
- CPU fan connector: Yes
- Number of COM connectors: 1
- Number of SATA III connectors: 4
- RGB LED pin header: Yes
- ATX Power connector (24-pin): Yes
- Number of chassis fan connectors: 4
- Front panel audio connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- USB 2.0 connectors: 2
- Thunderbolt headers: 1
Packaging data:
- Package depth: 273 mm
- Package weight: 1.36 kg
- Package width: 338 mm
- Package height: 68 mm
Storage controllers:
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- RAID levels: 1, 0, 10
- Number of storage drives supported: 7
- RAID support: Yes
Rear panel I/O ports:
- Ethernet LAN (RJ-45) ports: 1
- Headphone outputs: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- DisplayPorts quantity: 1
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- Microphone in: Yes
- HDMI ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB 2.0 ports quantity: 4
- Line-in: Yes
- S/PDIF out port: No
Expansion slots:
- Number of M.2 (M) slots: 3
- PCI Express x16 (Gen 4.x) slots: 2
- PCI Express x1 (Gen 4.x) slots: 2
