Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Core™ i7, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i9, Intel® Pentium® Gold
- Processor manufacturer: Intel
- Processor socket: LGA 1700
- Supported processor sockets: LGA 1700
Features:
- Windows operating systems supported: Windows 10 x64, Windows 11
- Audio output channels: 7.1 channels
- Motherboard chipset family: Intel
- Motherboard chipset: Intel B760
- Motherboard form factor: micro ATX
Memory:
- Supported memory types: DDR5-SDRAM
- Supported memory clock speed (max): 7800 MHz
- Unbuffered memory: Yes
- Supported memory clock speeds: 6000, 5200, 6800, 5000, 5600, 7200, 4800, 7400, 5800, 5400, 6600, 6400, 7600, 7800, 7000, 6200
- Maximum internal memory: 192 GB
- Number of memory slots: 4
- ECC сompatibility: Non-ECC
- Memory slots type: DIMM
- Memory channels: Dual-channel
Weight & dimensions:
- Depth: 244 mm
- Height: 50 mm
- Width: 244 mm
Network:
- Ethernet LAN: Yes
- Wi-Fi: No
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Thunderbolt headers: 1
- Front panel audio connector: Yes
- Number of SATA III connectors: 4
- ATX Power connector (24-pin): Yes
- USB 2.0 connectors: 3
- 12V power connector: Yes
- Number of chassis fan connectors: 3
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- CPU fan connector: Yes
- EPS power connector (8-pin): Yes
Packaging data:
- Package width: 280 mm
- Package height: 71 mm
- Package weight: 1.65 kg
- Package depth: 265 mm
Packaging content:
- Screws included: Yes
- Cables included: SATA
Storage controllers:
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- RAID levels: 1, 10, 0, 5
- RAID support: Yes
- Number of storage drives supported: 7
- Number of HDDs supported: 4
Rear panel I/O ports:
- USB 2.0 ports quantity: 4
- DisplayPorts quantity: 1
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- S/PDIF out port: Yes
- Microphone in: Yes
- Ethernet LAN (RJ-45) ports: 1
- HDMI ports quantity: 1
- Headphone outputs: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Expansion slots:
- Number of M.2 (M) slots: 3
- PCI Express x16 (Gen 5.x) slots: 1
- PCI Express x1 (Gen 3.x) slots: 1
- PCI Express x4 (Gen 4.x) slots: 1
