Leírás és Paraméterek
Processor:
- Processor manufacturer: AMD
- Compatible processor series: AMD Ryzen 8000 Series, AMD Ryzen 7000 Series, AMD Ryzen 9000 Series
- Processor socket: Socket AM5
Features:
- Motherboard chipset: AMD X870
- Product colour: Multicolour
- Motherboard chipset family: AMD
- Motherboard form factor: ATX
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 11
- Component for: PC
Memory:
- Unbuffered memory: Yes
- Maximum internal memory: 256 GB
- Memory channels: Dual-channel
- Supported memory clock speed (max): 8000 MHz
- ECC сompatibility: ECC & Non-ECC
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- Number of memory slots: 4
Weight & dimensions:
- Width: 305 mm
- Depth: 244 mm
- Height: 48 mm
Network:
- Bluetooth: Yes
- Bluetooth version: 5.4
- Ethernet interface type: 2.5 Gigabit Ethernet
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- Ethernet LAN: Yes
- Wi-Fi: Yes
Internal I/O:
- S/PDIF out connector: Yes
- USB 2.0 connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- EPS power connector (8-pin): Yes
- TPM connector: Yes
- Chassis intrusion connector: Yes
- ATX Power connector (24-pin): Yes
- Number of CPU fan connectors: 1
- Number of chassis fan connectors: 4
- CPU fan connector: Yes
- Number of COM connectors: 1
- Number of SATA III connectors: 4
- Front panel audio connector: Yes
- 12V power connector: Yes
- USB 3.2 Gen 2x2 connectors: 1
BIOS:
- BIOS type: UEFI AMI
- BIOS memory size: 256 Mbit
Packaging data:
- Package width: 353 mm
- Package weight: 1.95 kg
- Package depth: 273 mm
- Package height: 68 mm
Storage controllers:
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- RAID levels: 0, 1, 10, 5
- RAID support: Yes
- Number of HDDs supported: 4
- Number of storage drives supported: 7
Rear panel I/O ports:
- HDMI ports quantity: 1
- Line-in: Yes
- Ethernet LAN (RJ-45) ports: 1
- USB connector type: USB Type-A, USB Type-C
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- WiFi-AP antenna jack: 2
- USB4 Gen 3x2 ports quantity: 2
- USB 2.0 ports quantity: 4
- Microphone in: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
Expansion slots:
- Number of M.2 (M) slots: 3
- PCI Express x16 (Gen 4.x) slots: 2
- PCI Express x16 (Gen 3.x) slots: 1
