Leírás és Paraméterek
Processor:
- Processor manufacturer: AMD
- Compatible processor series: AMD Ryzen 5000 Series, AMD Ryzen 3000 Series, AMD Ryzen 4000 Series
- Processor socket: Socket AM4
- Supported processor sockets: Socket AM4
Graphics:
- DirectX version: 12.0
- HDCP: Yes
Features:
- Audio chip: Realtek ALC897
- Motherboard chipset family: AMD
- Windows operating systems supported: Windows 11, Windows 10
- Motherboard chipset: AMD A520
- Audio output channels: 7.1 channels
- Motherboard form factor: micro ATX
- Supported processor sockets (cooler): Socket AM4
- Power source type: ATX
Memory:
- Memory slots type: SO-DIMM
- Supported memory clock speed (max): 4400 MHz
- Supported memory module capacities: 8GB, 32GB, 16GB
- ECC сompatibility: Non-ECC
- Supported memory clock speeds: 3200, 4266, 2133, 2400, 2667, 4400, 3800, 2933, 3600, 4133, 4000
- Memory channels: Dual-channel
- Maximum internal memory: 64 GB
- Number of memory slots: 2
- Supported memory types: DDR4-SDRAM
Weight & dimensions:
- Width: 235 mm
- Depth: 190 mm
Network:
- Ethernet LAN: Yes
- Wi-Fi: No
- LAN controller: Realtek RTL8111H
- Ethernet interface type: Gigabit Ethernet
- Bluetooth: No
Internal I/O:
- Audio connector: Yes
- Front panel connector: Yes
- Power fan connector: Yes
- Front panel audio connector: Yes
- Number of SATA III connectors: 4
- CPU fan connector: Yes
- ATX Power connector (24-pin): Yes
- USB 2.0 connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Storage controllers:
- Supported storage drive types: HDD & SSD
- RAID support: Yes
- Number of HDDs supported: 4
- RAID levels: 1, 0, 10
- Supported storage drive interfaces: M.2, PCI Express 3.0, SATA III
- Number of storage drives supported: 1
Rear panel I/O ports:
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- USB 2.0 ports quantity: 4
- Ethernet LAN (RJ-45) ports: 1
- Line-in: Yes
- HDMI ports quantity: 1
- Microphone in: Yes
- PS/2 ports quantity: 1
- Headphone outputs: 1
- VGA (D-Sub) ports quantity: 1
Expansion slots:
- PCI Express x16 slots: 1
- PCI Express x1 (Gen 3.x) slots: 2
