Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium®, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®
- Supported processor sockets: LGA 1700
- Processor manufacturer: Intel
- Processor socket: LGA 1700
Features:
- Audio chip: Realtek ALC897
- Motherboard form factor: micro ATX
- Motherboard chipset: Intel B760
- Cooling type: Passive
- Windows operating systems supported: Yes
- Audio output channels: 7.1 channels
- Motherboard chipset family: Intel
- Power source type: ATX
Memory:
- Memory slots type: DIMM
- Supported memory clock speeds: 5600, 4800, 6000, 5200, 5400
- Number of memory slots: 2
- Supported memory types: DDR5-SDRAM
- Maximum internal memory: 64 GB
Weight & dimensions:
- Width: 236 mm
- Depth: 208 mm
Network:
- Ethernet interface type: Gigabit Ethernet
- Ethernet LAN: Yes
- Yes (no WiFi card included): Yes (no WiFi card included)
Internal I/O:
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- TPM connector: Yes
- ATX Power connector (24-pin): Yes
- EPS power connector (8-pin): Yes
- Front panel audio connector: Yes
- Front panel connector: Yes
- Number of COM connectors: 1
- Number of M.2 (E) slots: 1
- USB 2.0 connectors: 2
- Number of SATA III connectors: 4
- Number of chassis fan connectors: 1
Packaging content:
- Cables included: SATA
- Drivers included: Yes
- Set contents: WiFi antenna accessories
Storage controllers:
- Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
- Supported storage drive types: HDD & SSD
Rear panel I/O ports:
- Audio ports quantity: 3
- VGA (D-Sub) ports quantity: 1
- DVI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- HDMI ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- PS/2 ports quantity: 1
- USB 2.0 ports quantity: 4
- Number of Wi-Fi antenna ports: 1
