Leírás és Paraméterek
Processor:
- Supported processor sockets: Socket AM5
- Processor socket: Socket AM5
- Processor manufacturer: AMD
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
Graphics:
- HDCP: Yes
- Parallel processing technology support: Not supported
- DirectX version: 12.0
Features:
- Motherboard chipset: AMD B850
- Motherboard form factor: micro ATX
- Audio chip: Realtek ALC897
- Motherboard chipset family: AMD
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Product colour: Black
Memory:
- Memory channels: Dual-channel
- Maximum internal memory: 128 GB
- Unbuffered memory: Yes
- ECC сompatibility: Non-ECC
- Supported memory types: DDR5-SDRAM
- Number of memory slots: 2
- Memory slots type: DIMM
- Supported memory clock speed (max): 8000 MHz
Weight & dimensions:
- Depth: 244 mm
- Width: 235 mm
Network:
- Bluetooth: Yes
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- LAN controller: Realtek RTL8125D
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
- Wi-Fi: Yes
Internal I/O:
- ATX Power connector (24-pin): Yes
- Number of COM connectors: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- Clear CMOS jumper: Yes
- Front panel connector: Yes
- TPM connector: Yes
- Number of SATA III connectors: 2
- USB 2.0 connectors: 2
- CPU fan connector: Yes
- EPS power connector (8-pin): Yes
- Front panel audio connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of CPU fan connectors: 1
- Number of EPS power connectors (8-pin): 1
- RGB LED pin header: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS jumper: Yes
Storage controllers:
- RAID support: Yes
- Supported storage drive types: HDD & SSD
- RAID levels: 1, 10, 0
- Supported storage drive interfaces: SATA III, PCI Express 4.0
- Number of storage drives supported: 4
Rear panel I/O ports:
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- HDMI ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- DisplayPorts quantity: 1
- DisplayPort version: 1.2
- HDMI version: 2.1
- USB connector type: USB Type-A
- USB 2.0 ports quantity: 2
- Number of Wi-Fi antenna ports: 2
- Microphone in: Yes
- WiFi-AP antenna jack: 2
- Headphone outputs: 3
Expansion slots:
- Number of M.2 (M) slots: 2
- 2nd M.2 largest key size: 2280
- 2nd M.2 highest PCI Express generation: 4.0
- 1st M.2 largest key size: 2280
- 1st M.2 highest PCI Express generation: 4.0
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x4 (Gen 4.x) slots: 1
