Processor:
- Processor manufacturer: Intel
- Compatible processor series: Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium®
- Maximum number of SMP processors: 1
- Processor socket: LGA 1200 (Socket H5)
Graphics:
- DirectX version: 12.0
- HDCP: Yes
Features:
- Audio chip: Realtek ALC897
- PC health monitoring: Voltage, CPU, Temperature, Fan
- Motherboard chipset family: Intel
- Motherboard form factor: micro ATX
- Audio output channels: 7.1 channels
- Motherboard chipset: Intel Z590
Memory:
- Memory channels: Dual-channel
- Supported memory clock speeds: 2400, 2800, 3800, 2133, 3200, 2666, 3866, 3733, 2933, 3600, 4000
- Memory slots type: DIMM
- Number of memory slots: 2
- Maximum internal memory: 64 GB
- Supported memory types: DDR4-SDRAM
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Depth: 226 mm
- Width: 185 mm
Network:
- Ethernet interface type: Gigabit Ethernet, Fast Ethernet
- Wi-Fi: No
- Ethernet LAN: Yes
- LAN controller: Intel® I219-V
Internal I/O:
- EPS power connector (8-pin): Yes
- USB 2.0 connectors: 1
- Number of COM connectors: 1
- ATX Power connector (24-pin): Yes
- Front panel audio connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of SATA III connectors: 4
- Number of chassis fan connectors: 2
- Power fan connector: Yes
- Front panel connector: Yes
- CPU fan connector: Yes
BIOS:
- BIOS type: UEFI
- Clear CMOS jumper: Yes
Packaging content:
- Drivers included: Yes
- Cables included: SATA
Storage controllers:
- RAID support: Yes
- Supported storage drive types: HDD & SSD
- RAID levels: 1, 10, 0, 5
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- HDMI version: 1.4
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- HDMI ports quantity: 1
- PS/2 ports quantity: 2
- VGA (D-Sub) ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 3.x) slots: 1
- PCI Express x1 (Gen 3.x) slots: 2
- Number of M.2 (M) slots: 1
