Leírás és Paraméterek
Power:
- DC voltage: 12 V
- Power supply type: DC
- Power consumption (typical): 4 W
Operational conditions:
- Operating relative humidity (H-H): 10 - 90%
- Operating temperature (T-T): -10 - 55 °C
Weight & dimensions:
- Width: 260 mm
- Depth: 237.9 mm
- Weight: 1 kg
- Height: 47.6 mm
Network:
- Ethernet LAN: Yes
- Ethernet interface type: Fast Ethernet
- Ethernet LAN (RJ-45) ports: 1
- Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P
Performance:
- Product colour: Black
- Audio formats supported: PCM, G.711 μ-law, G.711 A-law
- Maximum video resolution: 1920 x 1080 pixels
- Backup function: Yes
- Video streaming: Yes
- Video compression formats: H.265+, H.264+, H.265, H.264
- PTZ control: Yes
- Supported cameras: TVI, IP, HDCVI, AHD, CVBS
- Dual stream support: Yes
- Audio system: 2-way
- Maximum resolution of supported cameras: 6 Mpix
- Video capturing speed: 30 fps
- Video motion detection: Yes
- Analog signal format system: PAL, NTSC
- Operating system installed: Embedded LINUX
- Rack capacity: 1U
- Channels quantity: 4 channels
- Video loss detection: Yes
- Maximum frame rate: 60 fps
Packaging data:
- Package depth: 315 mm
- Package width: 333 mm
- Package height: 89 mm
- Package weight: 1.4 kg
Ports & interfaces:
- HDMI ports quantity: 1
- RS-485 ports: 1
- Audio output: 1 RCA
- BNC output ports: 1
- Audio input: 1 RCA
- Video input channels: 4 channels
- VGA (D-Sub) output ports: 1
- BNC input ports: 4
- USB 2.0 ports quantity: 2
Hard drive:
- Number of HDDs supported: 1
- HDD interface: SATA
- Built-in memory: No
- Maximum HDD capacity: 16 TB
