Leírás és Paraméterek
Power:
- DC voltage: 12 V
- Power supply type: DC
- Power consumption (typical): 15 W
Operational conditions:
- Operating relative humidity (H-H): 10 - 90%
- Operating temperature (T-T): -10 - 55 °C
Weight & dimensions:
- Width: 325 mm
- Height: 55 mm
- Weight: 1.23 kg
- Depth: 257.1 mm
Network:
- Ethernet LAN (RJ-45) ports: 1
- Ethernet interface type: Gigabit Ethernet
- Ethernet LAN: Yes
- Supported network protocols: HTTP, HTTPS, TCP / IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P
Performance:
- Multi-display modes: 36, 8, 16, 4, 1, 25, 9
- Maximum frame rate: 60 fps
- Maximum video resolution: 3840 x 2160 pixels
- Channels quantity: 16 channels
- Video capturing speed (NTSC): 30 fps
- Dual stream support: Yes
- Multi-display supported: Yes
- Motion sensor: Yes
- USB connectivity: Yes
- Video capturing speed: 30 fps
- Video compression formats: H.264, H.265, H.265+, H.264+
- Video streaming: Yes
- Video motion detection: Yes
- Video capturing speed (PAL): 25 fps
- Product colour: Black
- Backup function: Yes
- Audio input channels: 1 channels
- Internal: No
- Playback modes: Event, General, Smart, Tag, Instant
- Operating system installed: Embedded LINUX
- Rack capacity: 1U
- Analog signal format system: PAL, NTSC
- Video loss detection: Yes
- Audio formats supported: PCM, G.711 μ-law, G.711 A-law
- Audio output channels: 1.0 channels
- Audio system: 2-way
- Bit rate: 32 Kbit/s
Packaging data:
- Package depth: 117 mm
- Package weight: 2.11 kg
- Package height: 308 mm
- Package width: 372 mm
Ports & interfaces:
- BNC input ports: 16
- VGA (D-Sub) output ports: 1
- Video input channels: 16 channels
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
- USB 2.0 ports quantity: 2
- HDMI ports quantity: 1
- RS-485 ports: 1
Hard drive:
- Maximum HDD capacity: 16 TB
- HDD interface: SATA
- Number of HDDs supported: 1
