Features:
- Power protection features: Overload, Short circuit
- Maximum current: 16 A
- Output operation voltage (min): 195 V
- Input frequency: 50 Hz
- Output power capacity: 2.25 kVA
- UPS topology: Line-Interactive
- Input operation voltage (min): 178 V
- Number of input phases: 1
- Number of output phases: 1
- Surge protection: Yes
- Input operation voltage (max): 281 V
- Output power: 2250 W
- Emergency Power Off (EPO): Yes
- Automatic Voltage Regulation (AVR): Yes
- Waveform: Sine
- Output operation voltage (max): 253 V
Design:
- International Protection (IP) code: IP20
- Product colour: Black
- Display type: LCD
- Form factor: Rackmount/Tower
- Cooling type: Active
- LED indicators: Yes
Operational conditions:
- Operating relative humidity (H-H): 20 - 80%
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): 0 - 45 °C
- Storage relative humidity (H-H): 20 - 95%
- Operating altitude: 0 - 1000 m
Weight & dimensions:
- Width: 440 mm
- Depth: 460 mm
- Package height: 247 mm
- Height: 132 mm
- Weight: 28 kg
- Package width: 547 mm
Packaging data:
- Rubber feet: Yes
- Cables included: Input power cable
- Quick installation guide: Yes
- Manual: Yes
Ports & interfaces:
- AC outlet types: C19 coupler, C13 coupler
- Power plug: C20 coupler
- AC outlets quantity: 9 AC outlet(s)
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 1
Battery:
- Typical backup time at full load: 3 min
- Typical backup time at half load: 7 min
- Number of batteries supported: 4
- Battery capacity: 9 Ah
- Cold start: Yes
- Battery voltage: 12 V
- Battery recharge time: 4 h
