Leírás és Paraméterek
Design:
- On/off switch: Yes
- Fan location: Top
- Cooling type: Active
- Number of fans: 1 fan(s)
- Product colour: Black
- Fan diameter: 13.5 cm
Power:
- Max output current (+12V): 83.33 A
- Efficiency: 94%
- Combined power (-12V): 18.6 W
- AC input voltage: 100 - 240 V
- Power protection features: Over current, Overheating, Short circuit, Over voltage, Over power
- Max output current (-12V): 0.3 A
- Input current: 13-6 A
- Combined power (+5Vsb): 18.6 W
- Combined power (+12V): 1000 W
- Combined power (+5V): 120 W
- Combined power (+3.3V): 120 W
- AC input frequency: 50/60 Hz
- Max output current (+5V): 20 A
- Total power: 1000 W
- Max output current (+3.3V): 20 A
- Max output current (+5Vsb): 3 A
Weight & dimensions:
- Width: 150 mm
- Depth: 150 mm
- Height: 86 mm
Performance:
- 80 PLUS certification: 80 PLUS Titanium
- Noise level: 15 dB
- ATX version: 3.0
- Bearing technology: FDB
- Purpose: PC
- EPS version: 2.92
- Power supply unit (PSU) form factor: ATX
Ports & interfaces:
- CPU power connector (4+4 pin): Yes
- Peripheral (Molex) power connectors (4-pin): 4
- CPU power cable length: 70 cm
- Motherboard power connector: 20+4 pin ATX
- PCI Express power connectors (6+2 pin): 5
- Motherboard power cable length: 60 cm
- Number of SATA power connectors: 12
- Cabling type: Fully-Modular
- PCI Express power connectors (12+4 pin) cable length: 700 mm
