Leírás és Paraméterek
Design:
- Fan diameter: 4 cm
- Number of fans: 2 fan(s)
- Product colour: Black
Power:
- Power protection features: Overheating, Short circuit, Over voltage, Under voltage, Over current, Over power
- Max output current (+5Vsb): 3 A
- AC input frequency: 50 - 60 Hz
- Combined power (+5V): 130 W
- Max output current (+3.3V): 20 A
- Combined power (+3.3V): 130 W
- Power Factor Correction (PFC) type: Active
- Max output current (+12V): 58.3 A
- Efficiency: 90%
- Max output current (+5V): 20 A
- Input current: 10-5 A
- AC input voltage: 100 - 240 V
- Max output current (-12V): 0.5 A
- Total power: 700 W
Weight & dimensions:
- Width: 150 mm
- Depth: 190 mm
- Height: 86 mm
Performance:
- 80 PLUS certification: 80 PLUS Gold
- Purpose: Server
- Bearing technology: Ball bearing
- Power supply unit (PSU) form factor: PS/2
Ports & interfaces:
- CPU power connector (4+4 pin): Yes
- Number of SATA power connectors: 6
- Cabling type: Non-Modular
- Peripheral (Molex) power connectors (4-pin): 2
- PCI Express power connectors (6+2 pin): 4
- Motherboard power connector: 20+4 pin ATX
