Leírás és Paraméterek
Processor:
- Processor manufacturer: AMD
- Compatible processor series: 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 9, 3rd Generation AMD Ryzen™ 3
- Maximum number of SMP processors: 1
- Processor socket: Socket AM4
Graphics:
- Maximum graphics card memory: 16000 MB
- Maximum resolution: 4096 x 2160 pixels
- HDCP: Yes
Features:
- PC health monitoring: Voltage, Temperature, Fan
- Windows operating systems supported: Windows 10 x64
- Motherboard chipset family: AMD
- Motherboard form factor: micro ATX
- Motherboard chipset: AMD B550
Memory:
- Supported memory clock speeds: 2933, 3600, 4733, 2667, 4400, 2133, 2400, 3200, 3333, 4000, 4600
- Memory channels: Dual-channel
- Number of memory slots: 4
- Maximum internal memory: 128 GB
- Supported memory types: DDR4-SDRAM
- Memory slots type: DIMM
- Unbuffered memory: Yes
Weight & dimensions:
- Depth: 244 mm
- Width: 244 mm
Network:
- Ethernet interface type: Gigabit Ethernet
- Wi-Fi: No
- Ethernet LAN: Yes
Internal I/O:
- TPM connector: Yes
- CPU fan connector: Yes
- Front panel connector: Yes
- USB 2.0 connectors: 1
- Number of SATA III connectors: 4
- Front panel audio connector: Yes
- Serial port headers: 1
- RGB LED pin header: Yes
- 12V power connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of chassis fan connectors: 2
- ATX Power connector (24-pin): Yes
BIOS:
- Clear CMOS jumper: Yes
- BIOS type: UEFI AMI
- Desktop Management Interface (DMI) version: 2.7
Storage controllers:
- Supported storage drive interfaces: Serial ATA III
- RAID levels: 0, 10, 1
- Supported storage drive types: HDD & SSD
Rear panel I/O ports:
- HDMI ports quantity: 1
- HDMI version: 2.1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- PS/2 ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 4
- DVI-D ports quantity: 1
Expansion slots:
- PCI Express x16 slots: 2
- Number of M.2 (M) slots: 2
- PCI Express x1 (Gen 3.x) slots: 1
