Leírás és Paraméterek
Processor:
- Supported processor sockets: Socket AM5
- Processor manufacturer: AMD
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
- Processor socket: Socket AM5
Graphics:
- Parallel processing technology support: Not supported
- HDCP: Yes
- Maximum resolution: 4096 x 2160 pixels
- Discrete graphics support: Yes
- DirectX version: 12.0
Features:
- Motherboard form factor: ATX
- PC health monitoring: Fan, Water cooling, Voltage, Noise, Temperature
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Motherboard chipset: AMD B650
- Product colour: Black
- Power source type: ATX
- Component for: PC
- Audio output channels: 7.1 channels
- Motherboard chipset family: AMD
Memory:
- Supported memory clock speeds: 6400, 6600, 6000, 7000, 8000, 5200, 4400 MHz, 7600, 7800, 5600, 7200, 6200, 6666, 6800, 4800
- Supported memory types: DDR5-SDRAM
- Memory slots type: DIMM
- Number of memory slots: 4
- Unbuffered memory: Yes
- Maximum internal memory: 256 GB
- Supported memory clock speed (max): 8000 MHz
- Memory channels: Dual-channel
- ECC сompatibility: Non-ECC
- Maximum internal memory per slot: 64 GB
Weight & dimensions:
- Depth: 244 mm
- Width: 305 mm
- Height: 35 mm
Network:
- Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 5 (802.11ac), 802.11b
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- WLAN controller model: RZ616
- Bluetooth version: 5.2
- Wi-Fi: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- Ethernet LAN: Yes
- Bluetooth: Yes
Internal I/O:
- Front panel connector: Yes
- ATX Power connector (24-pin): Yes
- USB 2.0 connectors: 2
- Serial port headers: 1
- Number of chassis fan connectors: 6
- CPU fan connector: Yes
- 12V power connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Front panel audio connector: Yes
- TPM connector: Yes
- Number of water pump connectors: 3
- USB 3.2 Gen 2x2 connectors: 1
- EPS power connector (8-pin): Yes
- Number of RGB LED pin headers: 5
- Number of temperature sensor headers: 2
- RGB LED pin header: Yes
- Number of SATA III connectors: 4
BIOS:
- ACPI version: 5.0
- BIOS type: UEFI AMI
- Clear CMOS jumper: Yes
- Desktop Management Interface (DMI) version: 2.7
- BIOS memory size: 256 Mbit
- System Management BIOS (SMBIOS) version: 2.7
Packaging data:
- Package depth: 270 mm
- Package height: 80 mm
- Package weight: 2.49 kg
- Package width: 335 mm
Packaging content:
- Screws included: Yes
- Antenna included: Yes
- Batteries included: Yes
Storage controllers:
- RAID support: Yes
- Number of HDDs supported: 4
- RAID levels: 0, 1, 10
- Number of storage drives supported: 7
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- Ethernet LAN (RJ-45) ports: 1
- HDMI ports quantity: 1
- Microphone in: Yes
- S/PDIF out port: Yes
- DisplayPort version: 1.4
- HDMI version: 2.1
- USB 2.0 ports quantity: 2
- WiFi-AP antenna jack: 2
- Line-in: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
- DisplayPorts quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots:
- Number of M.2 (M) slots: 3
- 2nd M.2 highest PCI Express generation: 4.0
- PCI Express x16 (Gen 4.x) slots: 2
- 1st M.2 highest PCI Express generation: 5.0
- PCI Express x16 (Gen 3.x) slots: 1
- 2nd M.2 largest key size: 25110
- 3rd M.2 largest key size: 25110
- 1st M.2 largest key size: 25110
- 3rd M.2 highest PCI Express generation: 4.0
Battery:
- Number of battery cells: 1
- Battery weight: 3 g
- Lithium weight per battery: 0.07 g
- Battery type: CR2032
- Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Logistics data:
- Country of origin: China
- Products per shipping (inner) case: 1 pc(s)
