Leírás és Paraméterek
Processor:
- Processor manufacturer: Intel
- Supported processor sockets: LGA 1700
- Processor socket: LGA 1700
- Compatible processor series: Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
Graphics:
- Parallel processing technology support: Not supported
- Maximum resolution: 4096 x 2304 pixels
- HDCP: Yes
- Number of displays supported: 3
Features:
- PC health monitoring: Fan, Voltage, Water cooling, Temperature
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Motherboard chipset: Intel B760 Express
- Motherboard form factor: micro ATX
- Motherboard chipset family: Intel
- Audio output channels: 7.1 channels
Memory:
- Unbuffered memory: Yes
- Supported memory clock speeds: 2133, 3200, 2666, 4266, 2933, 3600, 3300, 5133, 4500, 3800, 3333, 3733, 4300, 4400 MHz, 5000, 4600, 3000, 5333 MHz, 3466, 4133, 4000, 3666, 4800, 4933, 2400, 4700, 3400, 3866
- Maximum internal memory: 64 GB
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Number of memory slots: 2
- Supported memory types: DDR4-SDRAM
Weight & dimensions:
- Width: 244 mm
- Depth: 225 mm
Network:
- Ethernet LAN: Yes
- Wi-Fi: No
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- S/PDIF out connector: Yes
- Front panel audio connector: Yes
- Front panel connector: Yes
- ATX Power connector (24-pin): Yes
- Number of SATA III connectors: 4
- EPS power connector (8-pin): Yes
- TPM connector: Yes
- USB 2.0 connectors: 2
- CPU fan connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Serial port headers: 1
- 12V power connector: Yes
- RGB LED pin header: Yes
BIOS:
- Clear CMOS jumper: Yes
- BIOS type: UEFI AMI
- Desktop Management Interface (DMI) version: 2.7
Storage controllers:
- Number of storage drives supported: 6
- RAID levels: 10, 1, 0, 5
- RAID support: Yes
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Rear panel I/O ports:
- Headphone outputs: 3
- DisplayPorts quantity: 1
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- HDMI version: 2.0
- USB connector type: USB Type-A, USB Type-C
- PS/2 ports quantity: 1
- VGA (D-Sub) ports quantity: 1
- Microphone in: Yes
- HDMI ports quantity: 1
- DisplayPort version: 1.2
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Expansion slots:
- PCI Express x16 slots: 1
- Number of M.2 (M) slots: 2
- PCI Express x1 slots: 1
