Processor:
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
- Supported processor sockets: Socket AM5
- Processor manufacturer: AMD
- Processor socket: Socket AM5
- Maximum internal memory supported by processor: 256 GB
Graphics:
- Parallel processing technology support: Not supported
- On-board graphics card: No
- DirectX version: 12.0
Features:
- Motherboard form factor: ATX
- Motherboard chipset family: AMD
- PC health monitoring: Fan, Voltage, Temperature
- Windows operating systems supported: Windows 11 x64
- Product colour: White
- Motherboard chipset: AMD X870E
- Audio output channels: 7.1 channels
- Audio chip: Realtek ALC1220
Memory:
- Supported memory types: DDR5-SDRAM
- Supported memory module capacities: 1GB, 12GB, 24GB, 8GB, 32GB, 2GB, 4GB
- Supported memory clock speeds: 6000, 6600, 6800, 6400, 5600, 7000, 8200 MHz, 4800, 6200, 4400 MHz, 8000, 7600, 7800
- Number of memory slots: 4
- ECC сompatibility: Non-ECC
- Supported memory clock speed (max): 8200 MHz
- Memory channels: Dual-channel
- Unbuffered memory: Yes
- Memory slots type: DIMM
- Maximum internal memory per slot: 64 GB
- Maximum internal memory: 256 GB
Weight & dimensions:
- Height: 35 mm
- Depth: 244 mm
- Width: 305 mm
Network:
- Bluetooth version: 5.3
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- LAN controller: Realtek RTL8125
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Wi-Fi standards: Wi-Fi 7 (802.11be)
- Ethernet interface type: 2.5 Gigabit Ethernet
- Bluetooth: Yes
- WLAN controller model: Qualcomm QCNCM865
Internal I/O:
- Number of SATA III connectors: 4
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- RGB LED pin header: Yes
- USB 2.0 connectors: 2
- TPM connector: Yes
- CPU fan connector: Yes
- USB 3.2 Gen 2x2 connectors: 1
- EPS power connector (8-pin): Yes
- Number of CPU fan connectors: 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Number of chassis fan connectors: 6
- Number of water pump connectors: 2
- Number of RGB LED pin headers: 4
- Audio connector: Yes
- Number of EPS power connectors (8-pin): 1
BIOS:
- Clear CMOS button: Yes
- Clear CMOS jumper: Yes
- Desktop Management Interface (DMI) version: 2.7
- BIOS type: UEFI AMI
Packaging data:
- Package weight: 2.74 kg
- Package width: 345 mm
- Package depth: 294 mm
- Package height: 80 mm
Packaging content:
- Screws included: Yes
- Batteries included: Yes
- Antenna included: Yes
Storage controllers:
- Supported storage drive types: HDD & SSD
- RAID levels: 1, 10, 0
- Number of HDDs supported: 4
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
- Number of storage drives supported: 2
Rear panel I/O ports:
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- DisplayPort version: 1.4
- Headphone outputs: 1
- HDMI version: 2.1
- HDMI ports quantity: 1
- USB4 Gen 2x2 ports quantity: 2
- USB 2.0 ports quantity: 2
- Microphone in: Yes
- WiFi-AP antenna jack: 2
- S/PDIF out port: Yes
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x4 slots: 2
- PCI Express x16 (Gen 3.x) slots: 1
- Number of M.2 (M) slots: 4
- 3rd M.2 highest PCI Express generation: 5.0
- 4th M.2 highest PCI Express generation: 4.0
- 1st M.2 largest key size: 25110
- PCI Express x16 (Gen 5.x) slots: 1
- 2nd M.2 highest PCI Express generation: 5.0
- 2nd M.2 largest key size: 22110
- 1st M.2 highest PCI Express generation: 5.0
- 3rd M.2 largest key size: 22110
- 4th M.2 largest key size: 22110
Battery:
- Battery technology: Lithium-Manganese Dioxide (LiMnO2)
- Battery type: CR2032
- Number of battery cells: 1
- Battery weight: 3 g
- Lithium weight per battery: 0.07 g
Logistics data:
- Country of origin: China
- Products per shipping (inner) case: 1 pc(s)
