Design:
- Mounting type: Wall
- International Protection (IP) code: IP67
- Product colour: White
- Housing material: Metal, Plastic
Power:
- Power consumption (Power over Ethernet (PoE)): 9 W
- Power source type: DC, PoE
- Power consumption (max): 7.5 W
- DC output voltage: 12
- DC output current: 0.62 A
Security:
- Video motion detection: Yes
- Password protection: Yes
- Heartbeat: Yes
- Mirror: Yes
Operational conditions:
- Operating temperature (T-T): -30 - 60 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Storage temperature (T-T): -30 - 60 °C
Weight & dimensions:
- Height: 69.1 mm
- Weight: 315 g
- Width: 179 mm
- Depth: 67.4 mm
Network:
- Ethernet LAN: Yes
- Ethernet interface type: Fast Ethernet
- Bluetooth: No
- Wi-Fi: No
- Networking standards: IEEE 802.3af
- Quality of Service (QoS) support: Yes
- Number of users: 32 user(s)
Performance:
- Infrared (IR) cut-off filter: Yes
- Connectivity technology: Wired
- Wide Dynamic Range (WDR): 120 dB
- Type: IP security camera
- Day/night mode: Yes
- Placement supported: Outdoor
Packaging data:
- Package height: 118 mm
- Package width: 216 mm
- Package weight: 520 g
- Package depth: 121 mm
Storage:
- Card reader integrated: Yes
- Compatible memory cards: MicroSDHC, MicroSDXC, MicroSD (TransFlash)
- Maximum memory card size: 512 GB
Camera:
- Tilt angle range: 0 - 90°
- Camera shutter speed: 1/3 - 1/100000 s
- Pan range: 0 - 360°
- Angle of rotation: 360°
- Lens viewing angle, vertical: 54°
- Lens viewing angle, diagonal: 114°
- Lens viewing angle, horizontal: 98°
Image sensor:
- Progressive scan: Yes
- Sensor type: CMOS
- Optical sensor size: 25.4 / 3 mm (1 / 3")
Video:
- Privacy masking: Yes
- Maximum resolution: 2560 x 1440 pixels
- Total megapixels: 4 MP
- Supported graphics resolutions: 1920 x 1080 (HD 1080), 2560 x 1440, 640 x 480 (VGA), 640 x 360, 1280 x 720 (HD 720)
- Bit rate: 32 Kbps - 8 Mbps
- Highlight Compensation (HLC): Yes
- Video compression formats: M-JPEG, H.264, H.264+, H.265+, H.265
- Noise reduction: Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Region of Interest (ROI) encoding: Yes
- Frame rate: 25 fps
Night vision:
- Night vision: Yes
- Infra-red wavelength: 850 nm
- Night vision distance: 30 m
- LED type: IR/White
Lens system:
- Maximum aperture number: 1.6
- Identify distance (wide): 6 m
- Detect distance (wide): 63 m
- Observe distance (wide): 25 m
- Recognize distance (wide): 12 m
- Fixed focal length: 2.8 mm
