Leírás és Paraméterek
Design:
- IK code: IK08
- International Protection (IP) code: IP67
- Housing material: Plastic, Metal
- Form factor: Dome
- Product colour: White
Power:
- Power consumption (Power over Ethernet (PoE)): 7.5 W
- DC output current: 0.5 A
- DC output voltage: 12
- Power consumption (max): 6 W
- Power source type: DC, PoE
Security:
- Video motion detection: Yes
- Heartbeat: Yes
- Mirror: Yes
- Password protection: Yes
- Anti-flicker: Yes
Operational conditions:
- Operating relative humidity (H-H): 0 - 95%
- Operating temperature (T-T): -30 - 60 °C
- Storage relative humidity (H-H): 0 - 95%
- Storage temperature (T-T): -30 - 60 °C
Weight & dimensions:
- Package depth: 150 mm
- Height: 97.7 mm
- Diameter: 12.1 cm
- Package height: 141 mm
- Package weight: 800 g
- Package width: 150 mm
- Weight: 550 g
Network:
- Ethernet interface type: Fast Ethernet
- Number of users: 32 user(s)
- Wi-Fi: No
- Ethernet LAN: Yes
- Bluetooth: No
- Quality of Service (QoS) support: Yes
- Networking standards: IEEE 802.3af
Performance:
- Infrared (IR) cut-off filter: Yes
- Placement supported: Outdoor
- Day/night mode: Yes
- Wide Dynamic Range (WDR): 120 dB
- Connectivity technology: Wired
- Type: IP security camera
Audio:
- Voice codecs: G.711ulaw, MP2L2, G.726, PCM, G.711alaw, G.722.1
- Sample rate: 8 kHz / 16 kHz
Camera:
- Pan range: 0 - 355°
- Angle of rotation: 355°
- Camera tilt control: Yes
- Lens viewing angle, horizontal: 98°
- Camera shutter speed: 1/3 - 1/100000 s
- Lens viewing angle, diagonal: 114°
- Tilt angle range: 0 - 75°
- Lens viewing angle, vertical: 54°
Image sensor:
- Sensor type: CMOS
- Progressive scan: Yes
- Number of sensors: 1
- Optical sensor size: 25.4 / 3 mm (1 / 3")
Video:
- Video compression formats: H.264, H.265, H.265+, M-JPEG, H.264+
- Bit rate: 32 Kbps - 8 Mbps
- Frame rate: 25 fps
- Privacy masking: Yes
- Noise reduction: Yes
- Region of Interest (ROI) encoding: Yes
- Highlight Compensation (HLC): Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Total megapixels: 4 MP
- Maximum resolution: 2560 x 1440 pixels
- Supported graphics resolutions: 640 x 480 (VGA), 1920 x 1080 (HD 1080), 2560 x 1440, 1280 x 720 (HD 720), 640 x 360
Night vision:
- LED type: IR/White
- Night vision: Yes
- Night vision distance: 30 m
- Infra-red wavelength: 850 nm
Lens system:
- Fixed focal length: 2.8 mm
- Maximum aperture number: 1.6
